Product Details Introduction

Siemens 6ESP2714-1BD21-0XB0 is a CPU 224 DC/DC programmable controller in the SIMATIC S7-200 series. This controller is designed specifically for small and medium-sized automation tasks, with powerful processing capabilities and flexible scalability, making it very suitable for automation control tasks in various industrial applications.

Main technical specifications:

Type: SIMATIC S7-200 CPU 224 DC/DC/DC

Input/output points:

14 digit inputs

10 digital outputs (transistor output)

Power supply voltage: DC power supply, operating voltage range is 20.4 V to 28.8 V DC.

Storage capacity:

Program memory: 12 KB

Data storage: 10 KB

Communication interface:

1 RS-485 interface: supports PPI (point-to-point communication), MPI (multi-point communication), and free port mode.

Output type: transistor output, suitable for high-speed switching and control.

Instruction execution time: The basic instruction execution time is 0.22 microseconds per instruction, supporting real-time control.

Scalability: Can connect up to 7 expansion modules, increase input/output points or special function modules.

Operating temperature: Suitable for industrial environments ranging from 0 ° C to 55 ° C.

Functional features:

Compact design with high-density I/O: 14 digital inputs and 10 digital transistor outputs, suitable for applications that control multiple devices.

Transistor output: Transistor output has fast response capability and is very suitable for controlling devices that require high-speed switching, such as electric motors and automated production equipment.

Powerful storage capacity: 12 KB of program memory and 10 KB of data memory, capable of storing and running complex control logic.

Communication interface: The RS-485 interface supports multiple communication protocols, such as PPI and MPI, and can integrate communication with other PLCs, HMIs, or smart devices, making it suitable for distributed control applications.

Flexible Expansion: Supports connecting expansion modules, which can add more I/O points or functional modules according to specific needs, such as analog input/output modules, communication modules, etc.

High speed instruction execution: 0.22 microseconds/instruction execution speed, enabling it to cope with high demand real-time control applications.

Product image
