Siemens 6ES7214-1BD22-0XB0 Controller Module

Siemens 6ES7214-1BD22-0XB0 Controller Module

Product Details Introduction

Siemens 6ES7214-1BD22-0XB0 is a CPU 224 DC/DC controller module in the SIMATIC S7-1200 series. This module is widely used in small and medium-sized automation control systems, suitable for industrial automation, building management, and various process control tasks.

Main technical specifications:

Type: SIMATIC S7-1200 CPU 224 DC/DC/DC Controller Module

Input/output points:

14 digit inputs

10 digital outputs (transistor output)

Power supply voltage: The working voltage range is 20.4 V to 28.8 V DC, suitable for DC power supply systems.

Storage capacity:

Program memory: 24 KB

Data storage: 10 KB

Communication interface:

1 RS-485 interface, supporting PPI (point-to-point communication), MPI (multi-point communication), and free port mode.

Output type: Using transistor output, suitable for fast switching and control applications.

Instruction execution time: The basic instruction execution time is 0.22 microseconds per instruction, ensuring the effectiveness of real-time control.

Scalability: Supports up to 7 expansion modules, and can increase the number of input and output points or functional modules according to needs.

Working temperature: Suitable for industrial environments ranging from 0 ° C to 60 ° C.

Functional features:

Compact design: Provides abundant I/O points, suitable for control in environments with limited space.

High speed output: The transistor output achieves fast response and is suitable for devices that require switching speed.

Powerful storage capability: Provides sufficient program and data storage space to support complex control logic and applications.

Flexible communication interface: supports multiple communication protocols, can be easily integrated with other devices and systems, and enhances the flexibility and adaptability of the system.

Scalability: By connecting expansion modules, the I/O configuration of the system can be flexibly adjusted according to actual needs to meet different control requirements.

Efficient execution capability: The fast instruction execution time enables it to cope with high demand real-time control applications.

Product image
