Product Details Introduction

Siemens 6ES7214-1CC01-0XB0 is a controller unit in the SIMATIC S7-1200 series, designed specifically for small and medium-sized automation control systems, suitable for various industrial automation applications. It combines high-performance processing capabilities with flexible expansion options, and is widely used in fields such as manufacturing, process control, and building automation.

Main technical specifications:

Type: SIMATIC S7-1200 Controller Unit (CPU 224 AC/DC/Rly)

Input/output points:

14 digit inputs

10 digital outputs (relay outputs)

Power supply voltage:

Operating voltage range: 85 V to 264 V AC or 20.4 V to 28.8 V DC

Support AC and DC power supply

Storage capacity:

Program memory: 24 KB

Data storage: 10 KB

Communication interface:

1 RS-485 interface, supporting PPI (point-to-point communication), MPI (multi-point communication), and free port mode

Instruction execution time: The basic instruction execution time is 0.22 microseconds per instruction, which can meet real-time control requirements

Scalability: Supports up to 7 expansion modules, increases I/O points or functional modules as needed

Operating temperature: Suitable for industrial environments ranging from 0 ° C to 60 ° C

Functional features:

Multiple power options: Supports AC and DC power supply, increasing the flexibility of the system.

Compact design: This module is compact and designed to fit environments with limited space.

Fast response: The relay output supports high switching frequencies, making it suitable for control applications that require fast switching.

Powerful storage capacity: sufficient program and data storage space to support complex control logic.

Flexible communication capability: able to communicate with multiple devices, facilitating integration into various systems.

Scalability: It can easily increase the number of I/O points through expansion modules, flexibly adapting to different application needs.

Product image
