Siemens 6ES7214-2AD23-0XB0 Compact Unit

Siemens 6ES7214-2AD23-0XB0 Compact Unit

Product Details Introduction

Siemens 6ESC214-2AD23-0XB0 is a compact control unit (Compact CPU) in the SIMATIC S7-1200 series. It is a compact unit that integrates CPU and I/O modules, designed specifically for small and medium-sized automation control tasks, providing high-performance processing capabilities and rich communication interfaces. It is widely used in fields such as industrial automation, process control, and building management.

Main technical specifications:

Product Name: SIMATIC S7-1200 Compact CPU

CPU model: CPU 1214C

Input/output points:

14 digit inputs

10 digital outputs (relay outputs)

2 analog inputs

Power supply voltage:

Working voltage range: DC 20.4V to 28.8V

Storage capacity:

Program memory: 50 KB

Data storage: 2 KB

Communication interface:

PROFINET interface: 1 PROFINET interface, supporting Ethernet communication

RS-485 communication interface: used for point-to-point communication

Instruction execution time: The basic instruction execution time is 0.1 microseconds per instruction, supporting fast response and real-time control

Scalability: Supports up to 8 expansion modules for adding I/O or functional modules

Dimensions: Width 110 mm, Height 100 mm, Depth 75 mm

Working temperature: Applicable temperature range is 0 ° C to 60 ° C

Functional features:

Integrated design: The compact design integrates CPU, digital I/O, and analog inputs, making it suitable for small automation systems.

Flexible Scalability: Supports up to 8 expansion modules, allowing for flexible increase in I/O points or functional modules according to project requirements.

PROFINET communication: Built in PROFINET interface, supporting fast communication with upper computer, HMI and other devices.

Quick response: Short instruction execution time, suitable for automated tasks that require quick response.

Wide input voltage range: Supports 24V DC power input to meet the power requirements of various industrial sites.

Built in analog input: suitable for processing analog quantities such as temperature and pressure, expanding the application range of the controller.

Product image
