Siemens 6ES7222-1BF20-0XA0 Controller Module

Siemens 6ES7222-1BF20-0XA0 Controller Module

Product Details Introduction

Siemens 6ES7222-1BF20-0XA0 is a digital output module in the SIMATIC S7-200 series, mainly used to expand the digital output capability of PLC systems, and can control external devices such as relays, solenoid valves, lights, and other industrial equipment.

Main technical specifications:

Product model: 6ES7222-1BF20-0XA0

Module type: Digital output module

Number of output channels:

8 digital outputs, supporting 24V DC.

Output voltage:

24V DC.

Output current:

The maximum output current of each channel is 0.75A, and the total output current does not exceed 6A.

Short circuit protection:

Built in short-circuit protection function to ensure the safety of the output circuit.

Electrical isolation:

There is electrical isolation between the output and logic system, which enhances the stability and anti-interference ability of the system.

Installation method:

Supports DIN rail installation, suitable for control cabinet integration in standard industrial environments.

Size:

Width: 71.2 mm

Height: 80 mm

Depth: 62 mm

Main features:

8-way digital output:

Provide 8 high current capacity digital output channels for flexible control of multiple industrial equipment.

Short circuit protection:

Built in short-circuit protection mechanism to prevent circuit overload and damage.

Electrical isolation:

The electrical isolation design between the output and PLC system helps prevent external interference and ensure the reliability of signal transmission.

Modular design:

The module can be easily integrated into existing S7-200 systems for flexible expansion.

Strong applicability:

Suitable for digital device control in industrial automation, building control and other scenarios.

Application scenarios:

Industrial automation control:

Used to control digital devices such as actuators, motors, relays, etc. in factory automation systems.

Process control:

It can be used in process automation for outputting digital signals, controlling the execution of operations such as opening and closing valves or lights.

Building automation:

Applied in building management systems to control lighting, elevators, HVAC and other equipment.

Equipment management:

Can be used for controlling and managing the status of production equipment, achieving automation of production processes.

Summary:

The Siemens 6ES7222-1BF20-0XA0 digital output module provides 8 independent digital outputs for the SIMATIC S7-200 system. The module has short-circuit protection function and electrical isolation design, suitable for industrial automation, building control, and other scenarios that require high reliability digital signal output. It can help users effectively control and manage various industrial equipment, and easily integrate with existing systems.

Product image
