DS3820PSCB1C1B Analog Input Module

DS3820PSCB1C1B Analog Input Module

Product Details Introduction

Introduction to DS3820PSCB1C1B Analog Input Module

1. Overview: DS3820PSCB1C1B is an analog input module used in industrial control systems, typically applied in large automation systems, power plants, petrochemicals, and other fields. It can convert on-site analog signals (such as current and voltage signals) into digital signals that can be processed by the control system, achieving real-time monitoring and control of the status of on-site sensors or actuators.

2. Main characteristics

Multi channel analog input: This module supports multiple analog input channels and is suitable for applications involving multiple signal acquisition.

High precision signal acquisition: equipped with high-precision analog-to-digital conversion function, ensuring that the collected signals can truly reflect the on-site conditions.

Wide input range: Supports standard analog signal input, such as 0-10V, 4-20mA, etc.

Strong anti-interference ability: Built in signal filtering and anti-interference design ensure that the module can work stably in complex industrial environments.

Modular design: Supports hot swapping, making it easy to maintain and expand the system.

Communication interface: Typically equipped with standard industrial communication interfaces (such as Modbus, Profibus) for easy integration with main control systems (such as PLC, DCS).

3. Technical specifications

Analog input channels: 8 or 16 channels (depending on specific configuration)

Input signal type:

Voltage input: 0-5V, 0-10V

Current input: 4-20mA

Sampling accuracy: 12 bit or higher resolution analog-to-digital converter

Data transmission rate: high data refresh rate, adaptable to rapidly changing signal inputs

Working voltage: 24V DC

Working temperature range: -20 ° C to+60 ° C

Humidity range: 5% to 95% (no condensation)

4. Application Fields

Power plant: used for real-time monitoring and feedback control of key parameters such as temperature, pressure, and flow rate.

Petrochemical industry: Collect analog signals from sensors, and control systems adjust production processes based on input signals.

Automated production line: used to collect equipment working status parameters, achieve automatic control and optimization of the production process.

Building automation: Monitoring environmental parameters such as temperature and humidity in buildings, providing data support to optimize energy use.

5. Advantages and Value

High reliability: designed specifically for industrial applications, capable of stable operation in harsh environments.

Flexibility: Supports multiple types of analog signal inputs and can adapt to the access needs of various sensors and actuators.

Easy to maintain: Modular design supports online replacement and maintenance, reducing system downtime.

Precise control: The high-precision signal conversion capability ensures that the control system can accurately perform adjustment tasks.

6. System Integration and Communication

DS3820PSCB1C1B communicates with the upper control system through standard industrial communication protocols, supporting communication methods such as Modbus, Profibus, Ethernet/IP, etc. It can seamlessly integrate with programmable logic controllers (PLCs) and distributed control systems (DCS) to ensure the accuracy and timeliness of data transmission.

Product image
