Siemens 6ES7313-6BF03-0AB0 Input/Output Module

Siemens 6ES7313-6BF03-0AB0 Input/Output Module

Product Details Introduction

Siemens 6ES7313-6BF03-0AB0 is a CPU 313C-2 PtP module in the S7-300 series. Although it is primarily a central processing unit (CPU) module, it also integrates input/output (I/O) interfaces and point-to-point communication interfaces. This module is used to handle complex automation tasks, especially suitable for small and medium-sized automation systems. Its characteristics enable it to control multiple on-site devices while conducting efficient communication.

main features

Integrated I/O:

The module integrates 24 digital inputs and 16 digital outputs. These integrated I/O allow direct connection to field devices, reducing the need for additional I/O modules, saving space, and simplifying system design.

Point to point communication (PtP):

This module has a point-to-point communication interface (PtP), which can directly communicate with third-party devices or other control systems. This interface is very suitable for application scenarios that require efficient and real-time data exchange.

Medium performance processing capability:

The CPU 313C-2 PtP has a moderate processing speed and capacity, suitable for applications with moderate control tasks that do not require very high computing power. It has sufficient flexibility and processing power to meet the needs of industrial automation.

Modular design:

As a member of the S7-300 series, it can be combined with other I/O modules, communication modules, and functional modules to support flexible system expansion.

Multiple programming languages supported:

This module is compatible with Siemens STEP 7 software and supports common programming languages such as ladder diagram (LAD), functional block diagram (FBD), and statement table (STL), simplifying programming and fault diagnosis.

Integrated diagnostic function:

Built in diagnostic function can quickly identify and troubleshoot system faults, ensuring the reliability of the automation system.

technical specifications

Working memory: 64 KB

Loading memory: Supports MMC card expansion (up to 8 MB maximum)

Communication interface:

MPI interface (multi-point interface)

PtP interface (point-to-point communication interface)

Integrated I/O:

24 point digital input (DI)

16 point digital output (DO)

Power supply voltage: 24 V DC

Processing speed: approximately 100 ns/instruction

Working temperature: 0 ° C to 60 ° C

Size: 125 mm x 40 mm x 130 mm

Product image
