Product Details Introduction

Siemens 6ES7314-1AE02-0AB0 is an analog input module suitable for S7-300 series controllers, with the specific model being AI 314. This module is used to convert analog signals into digital signals and is widely used in industrial automation and control systems. The following are its main features and technical specifications:

Main features:

Number of channels:

It usually has 8 input channels and can receive multiple analog signals simultaneously.

Input type:

Supports multiple types of input signals, such as voltage (0-10V, ± 10V) and current (4-20mA, 0-20mA), with high flexibility.

resolving power:

Provide a resolution of 12 bits or higher to ensure the accuracy of signal acquisition.

Sampling time:

Supports fast sampling, suitable for real-time monitoring and control applications.

Fault diagnosis:

Built in fault detection function, which can monitor the status of input signals in real time, facilitating maintenance and troubleshooting.

Programming environment:

Compatible with Siemens STEP 7 software, channel parameters and sampling frequency can be set through programming.

Application areas:

Industrial automation: widely used in machine monitoring, process control, data acquisition and other scenarios.

Installation and configuration:

Installation: The module can be directly inserted into the S7-300 rack and supports hot swapping.

Configuration: Set up through STEP 7 software to adjust parameters according to different needs.

Product image
