Siemens 6ES7322-1BF01-0AA0 Digital Output Module

Siemens 6ES7322-1BF01-0AA0 Digital Output Module

Product Details Introduction

Siemens 6ES7322-1BF01-0AA0 is a digital output module for the S7-300 series, providing 8 channels of 24V DC output, suitable for controlling low-voltage digital signal output in industrial automation equipment.

Main technical specifications:

Number of output channels: 8 digital outputs

Output voltage: 24V DC

Maximum output current: 0.5 A per channel

Output type: Load type is DC load

Isolation voltage: 500V AC (between output and backplane bus)

Protection level: IP20

Electrical isolation: Electrical isolation between each channel and the backplane bus

Functional features:

8-way output: Provides 8 independent digital output channels, suitable for medium-sized device control needs.

24V DC output: The output voltage is 24V DC, which is compatible with a wide range of industrial equipment and sensors, such as solenoid valves, relays, etc.

Short circuit protection: With short circuit protection function, it automatically closes the corresponding channel when the output circuit fails, protecting the module and equipment.

Electrical isolation: There is a 500V isolation between the output signal and the backplane bus to ensure the safe and reliable operation of the system and prevent electrical interference.

Overload protection: The output module supports overload protection to prevent damage caused by excessive current and extend the system's lifespan.

Status indicator light: Each output channel is equipped with LED indicator lights, which display the status of the output channel in real time for easy debugging and maintenance.

Application scenarios:

Factory automation: suitable for controlling switches, relays, actuators, etc. in industrial production equipment, commonly used in automation control systems.

Process control: In a process control system, it is used to drive executing equipment, such as solenoid valves, motors, etc., to achieve automated operations.

Building automation: can be used to control equipment in building management systems, such as lighting systems, air conditioning equipment, etc.

Mechanical manufacturing: suitable for control signal output in mechanical equipment, driving various automation devices.

Summary:

Siemens 6ES7322-1BF01-0AA0 is a stable and reliable 8-channel 24V DC digital output module suitable for medium-sized industrial automation applications. This module provides short circuit and overload protection to ensure safe operation of the system in various industrial environments. Widely used in fields such as factory automation, process control, mechanical manufacturing, and building automation.

Product image
