Siemens 6ES7322-1BH00-0AA0 Digital Output Module

Siemens 6ES7322-1BH00-0AA0 Digital Output Module

Product Details Introduction

Siemens 6ES7322-1BH00-0AA0 is a digital output module for the S7-300 PLC series, providing 16 channels of 24V DC output, suitable for low-voltage digital signal control and equipment driving in industrial automation systems.

Main technical specifications:

Number of output channels: 16 digital outputs

Output voltage: 24V DC

Maximum output current: 0.5 A per channel

Total output current: maximum 4 A (8 channels per group)

Output type: Suitable for DC loads

Isolation voltage: 500V AC (between output and backplane bus)

Protection level: IP20

Electrical isolation: There is electrical isolation between the output channel and the backplane bus

Functional features:

16 output channels: Provides 16 independent 24V DC output channels, suitable for large-scale device control needs.

24V DC output: Standard 24V DC output, widely used in controlling solenoid valves, relays, actuators and other equipment.

Short circuit protection: Built in short circuit protection function ensures the protection of modules and connected devices from damage in case of circuit failure.

Electrical isolation: There is a 500V electrical isolation between the output and the backplane bus, enhancing the stability and safety of the module in industrial environments.

Overload protection: Supports overload protection function to avoid module damage caused by excessive output load and extend the service life of the system.

Status indicator light: Each output channel is equipped with an LED status indicator light, which displays the real-time working status of the channel for easy debugging and maintenance.

Modular design: Compatible with S7-300 series modular design, easy to integrate and expand, flexible to adapt to different industrial application needs.

Application scenarios:

Factory Automation: Suitable for controlling equipment on factory production lines, such as driving switches, relays, and actuators, to achieve automated production control.

Process control: Used for equipment control in process automation systems, such as driving solenoid valves, motors, etc., to ensure the smooth operation of automated production processes.

Building automation: can be used for building automation control, such as the control of lighting systems and HVAC equipment.

Mechanical manufacturing: suitable for controlling mechanical equipment, driving various automated actuators, and supporting the automation needs of mechanized production.

Summary:

Siemens 6ES7322-1BH00-0AA0 is a high-performance 16 channel 24V DC digital output module with functions such as short circuit protection, overload protection, and electrical isolation. It can operate reliably in various industrial application scenarios, such as factory automation, process control, building management, and mechanical manufacturing. The high reliability and scalability of the module make it an ideal choice for large-scale automation control systems.

Product image
