Siemens 6ES7322-1BH01-0AA0 Digital Output Module

Siemens 6ES7322-1BH01-0AA0 Digital Output Module

Product Details Introduction

Siemens 6ES7322-1BH01-0AA0 is a digital output module designed for the S7-300 series, featuring 16 24V DC output channels and specifically designed for controlling low-voltage digital devices in industrial automation systems.

Main technical specifications:

Number of output channels: 16 digital outputs

Output voltage: 24V DC

Maximum output current: 0.5 A per channel

Total output current: maximum 4 A (8 outputs per group)

Output type: Suitable for DC loads (such as solenoid valves, relays, etc.)

Isolation voltage: 500V AC (isolation between output and backplane bus)

Protection level: IP20

Electrical isolation: There is 500V isolation between the output signal and the backplane bus

Functional features:

16 output channels: Provides 16 independent 24V DC digital output channels, suitable for large-scale device control applications.

Short circuit protection: Equipped with a short circuit protection function, it can automatically close the corresponding channel when a circuit fault is detected, protecting the module and equipment.

Overload protection: Supports overload protection to prevent damage to the module caused by output current overload and extend equipment life.

Electrical isolation: There is electrical isolation between the output channel and the backplane bus to ensure safety and anti-interference capability in industrial environments.

Status indicator lights: Each channel is equipped with LED indicator lights that display real-time output status for easy debugging and monitoring of system operation.

Modular design: compatible with the S7-300 series modular structure, facilitating system integration and expansion, and meeting the needs of automation systems of different scales.

Application scenarios:

Factory automation: Used in factory production lines to control relays, actuators, switches, and other equipment, achieving automated production control.

Process control: used to drive solenoid valves, motors, and other equipment in process control systems to ensure the smooth progress of production process automation.

Building automation: suitable for equipment control in building management systems, such as lighting systems, ventilation systems, security equipment, etc.

Mechanical manufacturing: Used in mechanical automation systems to control execution equipment and drivers, achieving automated operations.

Summary:

The Siemens 6ES7322-1BH01-0AA0 digital output module provides 16 channels of 24V DC output, with short-circuit, overload protection, and electrical isolation functions, ensuring safe and reliable operation in various industrial environments. It is widely used in fields such as factory automation, process control, building management, and mechanical manufacturing, and is an ideal choice for achieving large-scale automation systems.

Product image
