Siemens 6ES7322-1FF01-0AA0 Relay Output Module

Siemens 6ES7322-1FF01-0AA0 Relay Output Module

Product Details Introduction

Siemens 6ES7322-1FF01-0AA0 is a relay output module used in S7-300 series PLC systems, providing 8 relay outputs and suitable for controlling high voltage or high current loads.

Main technical specifications:

Number of output channels: 8 relay outputs

Contact type: normally open (NO) contact

Output voltage:

Maximum 230V AC

Maximum 24V DC

Maximum output current:

5A (AC voltage) per channel

5A (DC voltage) per channel

Switching power: Maximum 2000 VA (AC load) or 150 W (DC load)

Protection level: IP20 (suitable for installation inside control cabinets)

Electrical isolation: There is electrical isolation (500V AC) between the output channel and the backplane bus

Functional features:

Relay output: Provides 8 relay output channels, which can directly drive high voltage or high current loads, suitable for controlling equipment such as motors, solenoid valves, heaters, etc.

High load capacity: Each channel supports up to 5A load current, suitable for high-power load control.

Electrical isolation: There is a 500V AC electrical isolation between the output channel and the backplane bus, effectively preventing interference and ensuring the stability of system operation.

LED status indicator light: Each channel is equipped with LED indicator lights, which display the output status in real time for easy monitoring and maintenance.

Contact durability: Relay contact design has a high mechanical and electrical lifespan, suitable for applications that require frequent operation.

Application scenarios:

Factory automation: used to control the start/stop of large equipment such as motors, solenoid valves, or pumps.

Process control: Used in process control systems in industries such as chemical and pharmaceutical to drive heaters, fans, or other power equipment.

Building automation: Control high-power equipment such as lighting, air conditioning, and power supply systems to ensure efficient operation of building systems.

Mechanical manufacturing: In industrial machinery automation systems, directly controlling the power supply of equipment is suitable for high voltage or high current execution devices.

Summary:

Siemens 6ES7322-1FF01-0AA0 is a module with 8 relay outputs that can control loads up to 230V AC or 24V DC. Its high current carrying capacity and electrical isolation design make it particularly suitable for applications that require control of high-power equipment, such as industrial automation, process control, building automation, and mechanical manufacturing.

Product image
