Product Details Introduction

Siemens 6ES7322-1FH00-0AA0 is a digital output module used in S7-300 series PLC systems, providing 16 relay output channels for controlling various load types. This module is designed for use in industrial automation environments and can effectively manage and control high voltage or high current equipment.

Main technical specifications:

Number of output channels: 16 relay outputs

Output type: Relay normally open (NO) contact

Output voltage:

Maximum 230V AC

Maximum 24V DC

Maximum output current: 5A per channel (suitable for AC and DC loads)

Switching capacity:

AC load maximum 2000 VA

DC load maximum 150 W

Protection level: IP20 (suitable for installation in control cabinets)

Electrical isolation: There is electrical isolation (500V AC) between the output channel and the backplane bus

Functional features:

16 relay outputs: Provides 16 independent relay output channels, each of which can control AC/DC loads up to 5A.

Relay design: The relay contacts are normally open (NO) and can directly control high-power devices such as motors, solenoid valves, and lighting fixtures.

High load capacity: Suitable for controlling high-power equipment in industrial environments, especially high current loads that require frequent switching.

Short circuit protection: Built in short circuit protection function to prevent module damage under fault conditions.

Electrical isolation: The electrical isolation between the output signal and the backplane bus ensures system stability and reduces external interference.

LED status indicator light: Each output channel is equipped with LED indicator lights to monitor the channel status in real-time, making it easy to debug and maintain.

Compact design: Compact size, suitable for automation control systems that require high-density output.

Application scenarios:

Factory automation: Control high-power loads such as motors, solenoid valves, heaters, etc. in industrial equipment to achieve automated operations.

Process control: In industries such as chemical, pharmaceutical, and food processing, control complex process equipment to ensure stable production processes.

Building automation: used in building management systems to control lighting, air conditioning, heating and other equipment, and optimize energy management.

Mechanical manufacturing: Control the motors and actuators in mechanical automation systems to ensure reliable operation of equipment.

Summary:

The Siemens 6ES7322-1FH00-0AA0 digital output module is a powerful 16 channel relay output module suitable for industrial automation and process control fields, capable of controlling high voltage and high current equipment. Its high load capacity and electrical isolation design ensure stable and reliable operation of the module in harsh industrial environments.

Product image
