Siemens 6ES7323-1BH01-0AA0 Input/Output Module

Siemens 6ES7323-1BH01-0AA0 Input/Output Module

Product Details Introduction

Siemens 6ES7323-1BH01-0AA0 is a digital output module in the S7-300 series, suitable for various industrial automation applications. It is an improved model of the 6ES7323-1BH00-0AA0 module, with similar functionality but possibly enhanced or optimized in certain details.

Main technical specifications:

Module type: Digital output module

Output type: 24V DC

Number of output channels: 16

Voltage range: 20.4 V to 28.8 V DC

Maximum output current: 0.5 A per channel, total current not exceeding 4 A

Short circuit protection: Each output has a short circuit protection function

Overload protection: Each output has overload protection function

Status indication: LED indicator light displays output status

Front connector: 40 pin front connector for cable connection

Diagnostic function: supports diagnostic function, which can detect the operating status and fault conditions of the module

Response time: Typical switching time is 0.1 ms

Size: 125 mm x 40 mm x 120 mm (height x width x depth)

Application scenarios:

This module is suitable for scenarios that require fast and accurate digital signal output, such as:

Factory automation

machine building

process control

Building automation system

characteristic:

High reliability: It has short-circuit and overload protection functions to ensure that the system will not be damaged in case of abnormalities.

Modular design: It can seamlessly integrate with other S7-300 series modules to expand system capabilities.

Fast response: A response time of 0.1 ms is suitable for high demand control applications.

Easy to maintain: Supports module hot swapping and easy replacement, reducing downtime.

The Siemens 6ES7323-1BH01-0AA0 module is highly suitable for complex industrial environments that require controlling multiple digital devices. With its excellent performance and protection mechanisms, it ensures system stability and efficiency.

Product image
