Product Details Introduction

Siemens 6ES7323-1BL00-0AA0 is a digital I/O module in the S7-300 series, integrating multiple digital input and output channels for industrial automation and control systems.

Main technical specifications:

Module type: Digital input/output module

Number of input channels: 32 digital inputs

Number of output channels: 32 digital output channels

Input voltage range: 24V DC (20.4V-28.8V)

Output voltage range: 24V DC

Input current: The typical current for each input channel is 7 mA

Maximum output current: 0.5 A per output channel, total current not exceeding 4 A

Short circuit protection: The module has a short circuit protection function to ensure the safety of the output channel

Overload protection: Each output channel has overload protection

Signal status indication: equipped with LED indicator lights, displaying the status of each input and output channel

Connection method: Use a 40 pin front connector for cable connection

Diagnostic function: Supports diagnostic function, which can detect the real-time operation status of the module and potential faults such as short circuit, overload, etc.

Power consumption: Typical low power consumption, suitable for large-scale integration

Size: 125 mm x 40 mm x 120 mm (height x width x depth)

Application areas:

The Siemens 6ES7323-1BL00-0AA0 module is particularly suitable for industrial scenarios that require large-scale digital input/output control, such as:

Manufacturing automation: Control the status signal input and equipment start/stop output of production line equipment.

Process control system: processes digital signals from various sensors and actuators.

Machine manufacturing: It can digitally control and monitor multiple devices.

Building automation: achieving monitoring and control of building facilities.

Module features:

High density input/output: This module has 32 inputs and 32 outputs, suitable for scenarios that require processing large amounts of digital signals.

Modular design: seamlessly integrated with other modules in the Siemens S7-300 series, allowing for flexible system scaling.

Complete protection functions: equipped with short circuit and overload protection, improving the safety and reliability of the system.

Fast response: The response time of digital input and output signals is short, suitable for high demand real-time control applications.

Diagnostic capability: Real time monitoring of the status of each input and output channel, able to quickly detect and provide feedback on system faults, facilitating maintenance.

Summary:

The Siemens 6ES7323-1BL00-0AA0 digital I/O module provides a wide range of input and output capabilities in industrial control systems, making it suitable for use in complex automation systems. With its excellent reliability, protection functions, and diagnostic capabilities, it can provide efficient control and monitoring solutions for industrial sites.

Product image
