Siemens 6ES7326-1BK01-0AB0 Input Module

Siemens 6ES7326-1BK01-0AB0 Input Module

Product Details Introduction

Siemens 6ES7326-1BK01-0AB0 is a digital input module in the S7-300 series, used to collect and process digital input signals from field devices such as sensors and switches. This module is an upgraded version that optimizes signal processing performance and is suitable for the field of industrial automation.

Main technical specifications:

Module type: Digital input module

Number of input channels: 32 inputs

Input voltage range: 24V DC (20.4V to 28.8V)

Input current: typically 7 mA per channel

Input type: SINK input (i.e. negative input)

Input signal isolation: Electrical isolation between the module and the backplane bus, with an isolation voltage of 500V AC

Input response time: typically 3.7 ms

Signal status indication: Each input channel is equipped with LED indicator lights to display the current signal status

Diagnostic function: equipped with error detection and diagnostic functions, such as detecting problems such as signal loss and cable short circuits

Power consumption: Typical low power consumption, supports 5V DC power supply

Size: 125 mm x 40 mm x 120 mm (height x width x depth)

Connection method: Wiring is done through a 40 pin front connector

Main features:

High density input: 32 input channels, suitable for application scenarios that require the collection of large amounts of digital signals.

Fast response: With a response time of 3.7 ms, it is suitable for control applications that require high real-time performance.

Modular design: This module can be seamlessly integrated into the Siemens S7-300 series, allowing for flexible expansion of automation systems.

Signal isolation: The electrical isolation between the signal and the backplane bus ensures the stability and anti-interference ability of signal transmission.

Diagnostic function: Real time monitoring of the status of each input channel and support for error detection, which helps with quick maintenance and troubleshooting.

LED status indicator: Each channel is equipped with LED indicator lights for easy viewing of the channel's working status.

Application areas:

Factory automation: Collecting status signals from sensors, switches, and other equipment for automated production control.

Process control: Monitor and process multiple digital input signals to achieve industrial process control.

Machine manufacturing: Used for signal input processing of complex mechanical equipment, such as equipment status monitoring and control signal acquisition.

Building automation: Used in building management systems to monitor the digital signal inputs of various devices.

Summary:

The Siemens 6ES7326-1BK01-0AB0 digital input module has high-density input channels, fast response time, and advanced diagnostic functions, making it very suitable for signal acquisition and control needs in industrial automation scenarios. The module design is robust and has efficient signal processing capabilities, providing reliable support for automation systems.

Product image
