Product Details Introduction

Siemens 6ES7331-7KF02-0AB0 is another analog input module in the Siemens SIMATIC S7 series, belonging to the S7-300 PLC system. Similar to 6ES7331-7KF01-0AB0, it is also mainly used for analog signal acquisition in industrial automation systems. The following are the main features and technical parameters of 6ES7331-7KF02-0AB0:

Main functions:

Analog input channel: This module provides 8 analog input channels, which can be used to connect various analog sensors, such as temperature sensors, pressure sensors, etc.

Input signal type: Supports voltage and current signals, including:

Voltage signal: 0-10V

Current signal: 4-20mA or 0-20mA

Resolution: With a resolution of up to 16 bits, it provides more accurate analog signal acquisition.

Configuration flexibility: Input types and measurement ranges can be configured through STEP 7 software to meet different application requirements.

Technical parameters:

Power supply voltage: 24V DC

Number of input channels: 8 channels (single ended)

Signal type: Supports current and voltage input

Input range:

Voltage: 0-10V

Current: 4-20mA or 0-20mA

Resolution: 16 bits, providing high-precision data acquisition.

Isolation: Electrical isolation is provided between channels and between power sources and signals to ensure the safe operation of the system.

Accuracy: ± 0.1% full scale, ensuring accurate analog signal reading.

Diagnostic function: Supports module self diagnosis and signal fault detection, facilitating fault location.

Installation method: Installed on a standard S7-300 system rack, DIN rail mounting.

Application scenarios:

This module is commonly used in analog signal acquisition and processing scenarios in industrial automation, especially in applications that require high-precision measurement, such as process control and sensor data acquisition in manufacturing. Typical application scenarios include automation control systems in industries such as chemical, energy, manufacturing, and pharmaceuticals.

Product image
