RAMIX PMC676TX controller board

RAMIX PMC676TX controller board

Product Details Introduction

RAMIX PMC676TX is a high-performance network interface controller board commonly used in embedded systems, communication devices, and industrial control applications. This controller board is based on the PCI Mezzanine Card (PMC) specification and has strong network processing capabilities, making it suitable for network applications that require high bandwidth and low latency.

Main features:

High performance network interface:

Supports Gigabit Ethernet interface, suitable for high bandwidth network transmission requirements.

It usually has multiple network ports, supports parallel processing and load balancing, and can handle large amounts of network communication tasks.

PCI Mezzanine Card (PMC) interface:

Compliant with PMC specifications, it can be directly inserted into embedded systems or host systems that support PMC cards, providing the function of expanding network interfaces.

PCI-X bus compatible, providing interfaces with high data transfer rates and low latency.

Processor acceleration:

The board integrates a dedicated network processor with efficient packet processing capabilities, reducing the load on the main processor.

This feature is particularly suitable for real-time network applications that require high throughput and low latency.

Rich network protocol support:

Supports standard network protocol stacks, including TCP/IP, UDP, etc., suitable for various network applications.

It also supports advanced network features such as VLAN, QoS (Quality of Service), etc. to optimize network performance and resource management.

Redundancy and fault tolerance:

This controller board supports redundant configuration of network interfaces, ensuring that the system can maintain normal operation even in the event of network channel failures.

It can handle redundant paths and enhance the reliability of the system.

Low power design:

The board adopts an optimized low-power design, suitable for long-term stable operation while reducing the overall power consumption of the system.

Operating system compatibility:

Supports multiple operating systems such as VxWorks, Linux, Windows, etc., providing drivers to facilitate user integration into various software environments.

Technical specifications:

Model: RAMIX PMC676TX

Interface type: PCI Mezzanine Card (PMC), compatible with PCI-X bus

Network interface: Gigabit Ethernet interface, supporting full duplex mode

Protocol support: TCP/IP, UDP, VLAN, QoS, etc

Operating system support: mainstream operating systems such as VxWorks, Linux, Windows, etc

Power consumption: Low power design, specific values depend on configuration

Board size: Complies with PMC standard size

Application scenarios:

Embedded system:

Suitable for high-performance embedded network applications, such as routers, firewalls, industrial network gateways, and other devices.

Industrial control:

Can be used for network communication in industrial control systems, such as networking modules for PLC control systems, supporting efficient device data transmission.

Communication equipment:

Widely used in telecommunications and data center equipment as a high-performance network interface for exchanging and routing data streams.

Military and Aerospace:

Due to its high reliability and performance, it is suitable for applications such as military, aerospace, etc. that require strict network performance.

Advantages:

High performance network processing: Suitable for network application scenarios that require processing large amounts of data, it can greatly improve the efficiency of network communication.

Strong compatibility: PMC interface and PCI-X bus have strong compatibility and are easy to integrate into various systems.

Low power consumption: suitable for embedded systems and industrial applications that require long-term stable operation.

Product image
