TRICONEX 8305A Distributed Control System

TRICONEX 8305A Distributed Control System

Product Details Introduction

TRICONEX 8305A is a module for distributed control systems (DCS), belonging to the Triconex series, widely used in the fields of industrial safety and control, especially in applications that require high safety and reliability, such as the petroleum, natural gas, chemical, power and other industries. The Triconex system is renowned for its high fault tolerance and Triple Modular Redundancy (TMR) architecture, ensuring stable and safe operation in critical mission environments.

The main features of the TRICONEX 8305A module are:

High Safety Integrity Level (SIL 3):

The TRICONEX 8305A is designed for applications that require high levels of safety and complies with SIL 3 (Safety Integrity Level 3) certification standards.

Suitable for critical applications such as emergency shutdown systems (ESD), fire and gas systems (FGS), and turbine machinery control (TMC), ensuring that the system can safely shut down or continue to operate in the event of an emergency.

Triple Modular Redundancy (TMR):

The 8305A module adopts TMR architecture and is equipped with three independent processing paths. Each path will undergo real-time mutual verification, and even if one of the paths fails, the system can continue to operate safely.

This architecture ensures high fault tolerance and availability of the system, making it suitable for continuous operation in any critical task environment.

Distributed Control Architecture:

The 8305A module supports distributed control, allowing multiple modules to be distributed in different locations for control. This can improve the flexibility of the system and reduce the risk of single point of failure.

Distributed architecture helps improve the control efficiency and safety of the entire factory or equipment.

Hot swappable function:

The 8305A module supports hot swapping, which means that the module can be replaced without shutting down the system, reducing downtime during maintenance.

This is very important for factories and industrial equipment that require uninterrupted operation, as it can significantly improve equipment availability.

Redundant communication:

Support redundant communication paths, even if one communication line fails, the system can still function normally through the backup path.

This dual guarantee improves the reliability of the system and ensures the continuous transmission of critical data.

Comprehensive diagnostic function:

The 8305A module has powerful self diagnostic capabilities, which can continuously detect system status, identify and isolate faults. This helps to detect potential issues in advance and take measures before they escalate.

In this way, the system can maintain high operational safety and reliability.

Compliance and Certification:

The TRICONEX 8305A complies with multiple industry standards, including the IEC 61508 safety standard, and is suitable for safety level applications up to SIL 2/3.

Module design can work reliably in harsh industrial environments, with characteristics such as high temperature resistance, moisture resistance, and electromagnetic interference resistance.

Application areas:

Emergency Shutdown System (ESD):

In high-risk environments such as petrochemicals and chemicals, the 8305A module is used in emergency shutdown systems to ensure that the system can respond immediately and safely shut down in the event of hazardous conditions.

Fire and Gas System (FGS):

In the fire and gas detection system, this module can monitor fires or gas leaks in real time and take corresponding measures according to the set safety strategy, such as activating alarms, closing valves, etc.

Turbine Mechanical Control (TMC):

The 8305A module is used to control and protect large rotating equipment such as gas turbines, compressors, etc., ensuring that the equipment operates within a safe range and performs protective actions when necessary.

Key process control:

Modules can be used in critical process control systems to manage complex process flows, ensure operational safety and efficiency, and reduce potential hazards.

Technical specifications:

Model: TRICONEX 8305A

System architecture: Triple Modular Redundancy (TMR)

Safety level: Compliant with SIL 3 certification, according to IEC 61508 standard

Communication: Supports redundant communication paths

Module features: hot swappable, real-time self diagnosis

Application areas: Emergency Shutdown (ESD), Fire and Gas Systems (FGS), Turbomachinery Control (TMC), etc

Environmental adaptability: Suitable for harsh industrial environments, with anti-interference ability

Product image
