PROSOFT MVI56E-MNETC Communication Module

PROSOFT MVI56E-MNETC Communication Module

Product Details Introduction

PROSOFT MVI56E-MNETC is a Modbus TCP/IP communication module designed specifically for Allen Bradley ControlLogix series controllers. This module can connect ControlLogix PLC with devices that support Modbus TCP protocol, and is widely used for data transmission and device integration in industrial automation, such as factory automation, energy management, process control, etc.

Product Features

Dual port Ethernet connection: The MVI56E-MNETC module has two independent Ethernet ports, supporting redundancy and load sharing to ensure communication stability and reliability.

High speed data transmission: Supports transmission rates of up to 10/100 Mbps, enabling efficient data exchange in harsh industrial environments.

Modular design: seamlessly integrated with the ControlLogix system, no additional power supply is required after inserting into the backplane, the module is plug and play, easy to maintain and replace.

Multi device connection: Supports multiple client/server connections, can communicate with multiple Modbus TCP/IP devices simultaneously, and enhances system flexibility.

Fault recovery: The module supports functions such as data caching and automatic reconnection, effectively reducing the risk of data loss caused by communication interruptions.

Powerful diagnostic function: Equipped with LED status indicator lights and module diagnostic tools, it facilitates real-time monitoring of module status and quick troubleshooting.

technical specifications

Network protocol: Supports Modbus TCP/IP protocol and is compatible with master/slave mode.

Transmission speed: 10/100 Mbps adaptive Ethernet port

Maximum number of connections: Supports up to 30 clients and 10 server connections

Power supply: 5V DC (powered through the ControlLogix backplane)

Environmental temperature: The working temperature range is from 0 ° C to 60 ° C, suitable for industrial environments

Installation type: Installed in the ControlLogix backplane slot, occupying one I/O slot

application area

Factory Automation: Integrated with the ControlLogix control system, it is used to transmit data from various sensors, actuators, and other devices to the central control room, achieving intelligent manufacturing and production monitoring.

Energy management: Used in industries such as electricity and water to collect and monitor real-time data from devices such as electricity meters and flow meters to improve resource management efficiency.

Process control: applied in industries such as petrochemicals, refining, and pharmaceuticals, it connects PLC with DCS or SCADA systems to achieve real-time monitoring and control of critical process data.

Transportation: In scenarios such as traffic signal control and tunnel monitoring, different network devices can be connected to achieve real-time data collection and command issuance.

Product image
