Product Details Introduction

The PROSOFT MVI56-MCM interface module is a communication module designed specifically for Allen Bradley ControlLogix series PLCs provided by ProSoft Technology. It is used to achieve communication interface connections between different devices and systems, especially devices that support Modbus and other industrial protocols, to assist automation systems in data acquisition, control, and monitoring. The flexibility and scalability of the MVI56-MCM module make it suitable for various industrial automation scenarios, such as production line control, data integration, remote device monitoring, etc.

main features

Multi protocol support:

Modbus RTU and Modbus TCP: Supports Modbus communication protocol, allowing connections with other Modbus devices such as remote I/O devices, HMI, sensors, etc.

Multi master-slave configuration: Supports configuration of Modbus master or slave roles, can connect multiple devices for data exchange.

Other industrial protocols: This module also supports other standard industrial protocols, which can be configured and managed according to requirements.

Compatible with Allen Bradley controllers:

As an interface module designed specifically for the ControlLogix and CompactLogix PLC series, the MVI56-MCM can be seamlessly integrated into Allen Bradley systems, providing additional communication capabilities.

Supports fast communication through EtherNet/IP network and direct configuration through RSLogix 5000/Studio 5000 programming software.

Multiple data types supported:

Support multiple data exchange points, including input/output points, registers, bit data, and floating data, to meet different industrial application requirements.

High data transmission rate, capable of supporting fast real-time control and data monitoring.

Easy to configure and use:

The configuration process is simple, and users can set it up through the standard interfaces in RSLogix 5000 or Studio 5000, reducing the complexity of programming and integration.

Provide a web configuration tool that allows users to access module settings through a browser, facilitating remote configuration and debugging.

High speed data exchange:

The module is capable of exchanging data at a high rate, supporting real-time data stream processing, and is suitable for efficient control and monitoring in industrial environments.

Redundancy and reliability:

Provide redundant functions and fault protection design to ensure reliable operation of the system at critical moments.

Powerful error detection and diagnostic functions help improve equipment availability and reduce the occurrence of failures.

technical specifications

Model: MVI56-MCM

Protocol support: Modbus RTU, Modbus TCP, EtherNet/IP

Communication interface: Supports Ethernet and RS-232/RS-485 (depending on the actual application).

Supported data types: digital quantity, analog quantity, hold register, discrete input/output, etc.

Input voltage: 24V DC (typical).

Data exchange rate: up to 115200 bps (Modbus RTU) and fast Ethernet TCP/IP connection.

Number of supported devices: Multiple Modbus devices can be connected, depending on network bandwidth and protocol configuration.

Installation method: Insert directly into the backplane slot of Allen Bradley ControlLogix PLC.

Working temperature: usually between 0 ° C and 60 ° C (standard industrial environment).

Installation method: DIN rail installation or direct insertion into the controller expansion slot.

Product image
