Woodward 3522-1004 servo drive

Woodward 3522-1004 servo drive

Product Details Introduction

Woodward 3522-1004 servo drive is a high-performance servo control device produced by Woodward Corporation, used to control precision mechanical components such as servo valves and servo actuators. This driver is widely used in fields such as energy, aviation, and industrial automation, and is known for its precise control performance and reliability.

Product Overview

Model: 3522-1004

Brand: Woodward

Type: Servo Drive

Function: Provide closed-loop control signals for driving servo valves or other precision actuators.

Main functions and features

High precision closed-loop control

Provide stable closed-loop feedback control for positioning or speed adjustment of high-precision servo systems.

Supports multiple control modes, including position control, speed control, and force control.

Compatible with multiple input signals

Support analog signal input (such as voltage or current) to flexibly adapt to different system requirements.

Compatible with various sensors such as potentiometers, differential transformers, etc., used for feedback signal acquisition.

High dynamic response

The driver design has fast dynamic response capability and can adapt to high-speed changing control requirements.

Especially suitable for scenarios that require precise positioning and high dynamic performance.

Overload and fault protection

Built in overcurrent, overvoltage, and short-circuit protection functions enhance the safety and reliability of equipment operation.

Support alarm output for easy system fault diagnosis.

Durability and environmental adaptability

Industrial grade design, adaptable to various harsh environments, ensuring stable operation under extreme temperature and vibration conditions.

technical specifications

Input voltage:

Supports standard industrial voltage range (specific voltage values depend on module configuration).

Output type:

Electric current drive: used to control servo valves or actuators.

Control mode:

Analog signal control (voltage or current input).

Support closed-loop feedback.

Dynamic performance:

High bandwidth, suitable for high dynamic applications.

Protection function:

overload protection

Short circuit protection

Temperature monitoring

Installation method:

Supports panel or rack installation.

Environmental adaptability:

Temperature range: -30 ° C to 65 ° C

Protection level: Suitable for industrial site use.

Product image
