ALLEN BRADLEY 1336-QOUT-SP23A Output Tester

ALLEN BRADLEY 1336-QOUT-SP23A Output Tester

Product Details Introduction

The Allen Bradley 1336-QOUT-SP23A output tester is a specialized equipment under Rockwell Automation for testing and verifying the output performance of the 1336 series frequency converters. This device is suitable for frequency converter maintenance, troubleshooting, and verification of output signal quality to ensure the normal operation of the frequency converter. It is widely used in industrial automation control systems.

Product Overview

Brand:

Allen Bradley (Rockwell Automation)

model:

1336-QOUT-SP23A

Equipment type:

Output tester, used for testing and diagnosing frequency converter systems.

major function

Output signal test:

Measure and verify the output voltage, frequency, and phase balance of the frequency converter.

Fault diagnosis:

Identify potential issues during the output phase, such as short circuits, overloads, waveform anomalies, etc.

Performance verification:

Ensure the output stability and accuracy of the frequency converter under different load conditions.

Simulated load conditions:

Simulate the actual operating environment and test the output performance of the frequency converter through the built-in load module.

Data recording:

Provide records and analysis of key parameters for subsequent maintenance or improvement.

technical specifications

Detailed parameter information

Applicable equipment Allen Bradley 1336 series frequency converter

Input power standard industrial power supply (AC/DC optional)

Measure parameter output voltage, frequency, phase sequence, waveform quality

Display mode: digital display (equipped with LCD or LED indicator lights)

Test interface standard connection terminals compatible with Allen Bradley devices

Operation mode: automatic testing/manual mode

Data communication supports USB or Ethernet interfaces for connecting to the upper computer

Environmental temperature -10 ° C to+55 ° C

Compact size and weight design for easy portability
