PM864AK01 3BSE018161R1 processor unit module

PM864AK01 3BSE018161R1 processor unit module

Product Details Introduction

Main functions and features

High performance processing capability

Equipped with a powerful CPU, it supports fast processing of complex logical control tasks.

High speed task cycle, suitable for real-time process control and data processing.

Modular design

It can be flexibly combined with I/O modules, communication modules, and redundant modules to adapt to various application scenarios.

Support hot swappable function for easy online maintenance and expansion.

Redundant support

Support CPU redundancy configuration, achieve high availability, suitable for critical control tasks.

Redundant switching is fast and seamless, ensuring continuous system operation.

Multiple communication interfaces

Built in Ethernet interface for communication with control network and upper computer.

Supports multiple protocols, including Modbus TCP/IP, PROFINET, EtherNet/IP, etc., to meet different industrial network requirements.

Strong environmental adaptability

Industrial grade design, capable of operating in harsh environments.

It has the ability to resist electromagnetic interference and vibration, and is suitable for various industrial environments.

Programming and Configuration

Compatible with ABB's Control Builder programming tool, supporting multiple programming languages according to IEC 61131-3 standard.

Support online debugging and diagnostic functions for easy troubleshooting and optimization.

technical specifications

Parameter details

Model PM864AK01 (3BSE018161R1)

High performance industrial processor

Memory capacity: Program storage: 4 MB; Data storage: 1 MB

Communication interface 2 x Ethernet (RJ45), supporting TCP/IP

Redundancy supports CPU and power redundancy

Working power supply 24V DC

Working temperature range -25 ° C to+70 ° C

Standard module size for easy control cabinet integration

Installation method: DIN rail or rack mounted installation

Compatibility for AC 800M series systems

application area

process automation

Complex process control in the petrochemical, pharmaceutical, food, and beverage industries.

Energy and Electricity

Automation and protection control of power plants and transmission and distribution systems.

manufacturing

Centralized control of automated production lines and equipment.

infrastructure

Centralized management of water treatment, heating, and cooling systems.

transport

Control of logistics and transportation systems such as ports and airports.

Product image
