HAI805 Analog Input Module

HAI805 Analog Input Module

Product Details Introduction

HAI805 analog input module is an analog signal acquisition module used in industrial automation and control systems, mainly responsible for receiving various analog signals (such as temperature, pressure, flow sensor signals, etc.) and converting them into digital signals for further processing. It is commonly used in fields such as automation control systems, building management systems, and process control. The following is a detailed introduction about the module:

Main features:

Analog signal input:

The HAI805 analog input module can receive different types of analog signals, such as current signals (4-20 mA), voltage signals (0-10V), etc. It can obtain signals from various sensors or transmitters and convert these signals into digital signals for transmission to the control system.

High precision acquisition:

This module typically uses high-precision A/D (Analog to Digital Conversion) technology, which can accurately convert analog signals into digital data. The accuracy is usually 12 bits or higher to ensure the accuracy of the data.

Multi channel input:

The HAI805 module usually has multiple input channels, which can simultaneously receive multiple signals from different sensors or devices. This makes it very useful in applications that require monitoring multiple parameters simultaneously, such as temperature, pressure, flow rate, etc.

Anti interference capability:

This module typically has strong resistance to electromagnetic interference (EMI) and is suitable for use in industrial environments. It can operate stably in environments with high noise levels.

Standardized interface:

The module is equipped with standard wiring terminals and interfaces (such as screw terminals or plug-in terminals) for easy connection with control systems and other devices. It usually supports standard industrial protocols such as Ethernet, Modbus, CAN, etc., making it easy to integrate with upper computer or PLC systems.

Fault diagnosis and monitoring:

Some HAI805 modules provide built-in fault diagnosis functions that can monitor the health status of input signals, such as signal loss or out of range, and report abnormal situations for maintenance.

Configuration flexibility:

The module usually allows the user to configure the range, precision and other relevant parameters of the input signal to adapt to the output signal range of different sensors.

Application areas:

Industrial automation:

In production lines and automation equipment, HAI805 module can be used to collect analog signals from sensors (such as temperature, pressure, liquid level, etc.) and transmit the data to PLC, SCADA system or upper computer for real-time monitoring and control.

Process control:

In industries such as chemical, petroleum, natural gas, and food processing, analog input modules are used to obtain process parameter data, monitor equipment operating status in real-time, and adjust process control based on sensor feedback.

Building automation:

In the building management system, the HAI805 module can be used to collect signals from environmental monitoring sensors (such as temperature and humidity, CO ₂ concentration, etc.) to ensure the comfort and safety of the building environment.

Energy Management:

The HAI805 module is used for energy monitoring and management systems to collect signals such as current and voltage, helping to manage and optimize energy use and reduce energy consumption.

Environmental monitoring:

In the field of environmental monitoring, it can work together with various environmental sensors to collect data on gas concentration, air quality, pollutants, etc., supporting environmental protection and monitoring work.

Product image
