Product Details Introduction

Emerson 1C31125G01 Digital Output Module is an industrial automation control system component produced by Emerson Process Management, specifically designed to provide digital signal output functionality in industrial control systems. This module is widely used in process automation, data acquisition, and control systems, especially in industries such as petrochemicals, power, and manufacturing.

Main features:

Digital output function:

Emerson 1C31125G01 is a digital output module that can convert logic signals from control systems into electrical signals and output them to actuators such as relays, valves, switches, etc. These output signals can control the start stop, on/off, and other operations of the device.

Reliability and Durability:

This module design has high reliability and durability, and can work stably in harsh industrial environments. It usually has characteristics such as anti vibration, anti-interference, high temperature resistance, and moisture resistance, and can adapt to various harsh working conditions.

compatibility:

As part of Emerson's automation system, the 1C31125G01 module is compatible with Emerson's DeltaV system and supports seamless integration with other modules of the control system. This makes the upgrade and expansion of the system more flexible.

Multi channel output:

This module typically has multiple digital output channels and supports controlling multiple execution elements or devices simultaneously. Each channel can work independently and provide level signals (such as 24V DC or 115V AC) output, suitable for various types of industrial equipment.

Real time control and monitoring:

Provide real-time feedback and status monitoring to help users ensure the accuracy and reliability of the control system. The LED indicator lights on the module can display the output status for easy diagnosis and maintenance.

Compact design:

This module adopts a compact design, occupying a small space in the control cabinet, and is suitable for environments with limited space.

Simplified installation and maintenance:

The installation process is simple and intuitive, and the modules usually support hot swapping function, which means replacing or adding modules during system operation without affecting the operation of other parts of the system. This greatly facilitates daily maintenance and upgrade work.

Technical specifications:

Output type: Digital signal output, common output voltages are 24V DC, 115V AC, or 230V AC (depending on application requirements and module configuration).

Number of output channels: usually includes multiple independent output channels, the specific number depends on the specific model and configuration. 1C31125G01 may include 8 or more digital output points.

Compatibility: Compatible with Emerson's DeltaV distributed control system (DCS) and able to integrate into existing automation systems.

Rated voltage: Supports standard 24V DC or other voltage levels to meet a wide range of application requirements.

Response time: With fast response time, it can achieve efficient control.

Indication function: LED status indicator light, used to display the working status of each output channel in real time, facilitating monitoring and troubleshooting by operators.

Installation method: Modules are usually installed on standard DIN rails for easy installation and disassembly.

Temperature range: usually supports a wide temperature working range (such as -20 ° C to+60 ° C), suitable for different industrial environments.

Product image
