Product Details Introduction

BENDER IRDH265-2 insulation monitoring equipment is an advanced device used to monitor the insulation status in electrical systems, widely used in power, industrial automation, construction, and other applications that require monitoring the insulation status. This device is particularly suitable for insulation monitoring of DC power systems and low-voltage electrical equipment, which can help users detect insulation faults in real time, thereby improving the safety and reliability of the system.

Main functions and features:

Insulation monitoring:

BENDER IRDH265-2 is mainly used to monitor the insulation condition of electrical systems and detect insulation faults between electrical equipment and cables. Its goal is to identify any insulation issues in advance and avoid the danger caused by insulation faults in the electrical system.

This device can be used to monitor the insulation status in IT systems (ungrounded systems) or LPS systems (low-voltage systems), ensure no ground current leakage, and prevent faults during system operation.

High precision detection:

IRDH265-2 is equipped with high-precision detection technology, which can accurately measure the insulation resistance of electrical systems. The device is capable of detecting very small current leaks and issuing an alarm before the insulation drops to a predetermined danger threshold, ensuring the safety of the system.

It adopts digital signal processing technology, which can improve the accuracy and stability of measurement, and is suitable for detection tasks in complex electrical environments.

Wide working voltage range:

BENDER IRDH265-2 is capable of supporting system monitoring at multiple voltage levels and is typically suitable for AC 50/60 Hz AC systems and DC systems (such as DC batteries and DC power transmission systems).

The applicable voltage range is wide, which can meet the monitoring needs in different industrial environments.

Alarm and warning functions:

The device has multiple built-in alarm settings. Once the insulation resistance in the electrical system drops to the set critical value (usually tens of megaohms), it will automatically issue visual and audible alarms to prompt operators to take timely measures.

It has multi-level alarm output and can be connected to external alarm devices, programmable logic controllers (PLCs) and other systems for more complex alarm linkage and response.

Continuous online monitoring:

IRD265-2 provides 24-hour uninterrupted online monitoring function, which can continuously perform real-time detection of the electrical system to ensure that it is always in a safe state during system operation.

The device is capable of recording monitoring data and alarm history, and can export data through USB interface or Modbus communication protocol for subsequent analysis and report generation.

User friendly operating interface:

BENDER IRDH265-2 is equipped with an intuitive LCD display screen that shows the current insulation status, resistance value, and alarm information, making it convenient for users to view and operate.

Users can configure and monitor the device through button operations or through remote monitoring software, supporting remote adjustment of alarm thresholds and other parameters.

Scalability and compatibility:

This device supports integration with other Bender products, especially with insulation monitoring and control systems (IMS) and other industrial control equipment, forming a complete monitoring and alarm system.

The support of Modbus RTU protocol enables IRDH265-2 to easily exchange data with PLCs, SCADA systems, etc., making it convenient for large-scale industrial applications.

High environmental adaptability:

The device is designed to be sturdy, with strong anti-interference ability and environmental adaptability. Even in industrial environments with high temperature, humidity, or strong electromagnetic interference, IRDH265-2 can work stably.

Its casing meets the IP54 protection level, which can prevent the intrusion of dust and water droplets, making it suitable for industrial applications that require high environmental protection.

Product image
