REXROTH R901089559 amplifier module

REXROTH  R901089559 amplifier module

Product Details Introduction

The REXROTH VT-VPCD-1-16/V0/1-P-1 (R901089559) amplifier module is an amplifier module produced by Bosch Rexroth for use in industrial automation control systems. It is mainly used to regulate and drive actuators such as electro-hydraulic servo valves and proportional valves to achieve high-precision flow and pressure control. This module is crucial in hydraulic systems, especially in applications that require precise control, such as automation machinery, robotics, aerospace, and other fields.

Main functions and features:

Signal amplification and conversion:

The VT-VPCD-1-16/V0/1-P-1 amplifier module is mainly used to amplify input signals, amplifying weak control signals (such as voltage signals output from controllers or sensors) to a level sufficient to drive electro-hydraulic proportional valves or servo valves. In this way, the module can control parameters such as flow rate, pressure, and position in the hydraulic system.

Its working principle is to convert the input electrical signal into a current signal suitable for driving the hydraulic valve, ensuring that the hydraulic actuator operates accurately according to the set value.

High precision control:

This amplifier module has high-precision signal conversion and adjustment capabilities, suitable for hydraulic systems that require high-precision position, speed, and pressure control.

By precisely controlling the opening of the hydraulic valve, the stability and response speed of the hydraulic system can be ensured, especially in high-speed and high-precision applications.

Wide range input signal:

The VT-VPCD-1-16/V0/1-P-1 amplifier module supports multiple input signal types, typically including analog voltage signals (such as 0-10V or 4-20mA), as well as other common industrial signal types. This enables the module to be compatible with various control systems and can be linked with different types of hydraulic control systems.

It supports a wide input voltage range, so it can be integrated with various standard industrial automation control systems to meet different application requirements.

Multiple protection functions:

Multiple safety protection functions such as overcurrent protection, over temperature protection, and short circuit protection can effectively prevent modules and other system components from being damaged in the event of a malfunction.

This module can monitor its working status in real time and automatically disconnect or adjust its working mode in case of abnormal situations, ensuring that the system will not cause greater problems due to amplifier module failures.

Accurate adjustment and response speed:

This amplifier module is designed to provide high-speed response and stability, making it suitable for applications that require high dynamic performance. It can quickly respond to changes in control signals, ensuring that the servo valves and proportional valves in the hydraulic system can be adjusted in the shortest possible time.

Temperature and environmental adaptability:

This module has strong environmental adaptability and can work normally within a certain temperature range. Its design complies with industrial standards and can operate stably in industrial environments such as high temperature, low temperature, and vibration.

Its high reliability enables it to provide stable amplification function even in harsh environments, ensuring the continuous and efficient operation of the hydraulic system.

Modular design:

VT-VPCD-1-16/V0/1-P-1 is a modular design amplifier module that facilitates installation, maintenance, and replacement in complex automation control systems. Its design usually has good compatibility and flexibility, and can adapt to different hydraulic systems and application requirements.

Product image
