Product Details Introduction

Motorola MVME167-33B is a high-performance industrial control system based on the VMEbus architecture, widely used in embedded computing, industrial automation, data acquisition, communication control and other fields. The system was designed and manufactured by Motorola (now NXP Semiconductors) to provide reliable performance in harsh industrial environments.

Main features of MVME167-33B:

Processor and Performance:

Equipped with a 33 MHz Motorola 68040 RISC processor, it has high processing power and is suitable for applications that require strong computing and real-time control.

Support multitasking operating systems, such as VxWorks, RTEMS, and other real-time operating systems (RTOS), to achieve real-time control functionality.

Memory configuration:

Provide a maximum of 128 MB DRAM (Dynamic Random Access Memory) to meet high bandwidth data processing and storage requirements.

Supports Flash storage (usually 4 MB or larger) for storing firmware, applications, and operating systems.

VMEbus architecture:

Adopting the VMEbus standard, it can provide efficient data transmission speed and scalability, supporting multiple VMEbus modules and peripherals.

Supports VME 64 bit expansion, with higher bandwidth, suitable for data intensive applications.

I/O interface:

Provide multiple serial interfaces (such as RS-232 and RS-422) for communication and data exchange.

Equipped with Ethernet network interface, supporting industrial Ethernet communication and remote data transmission.

Multiple GPIO (General Purpose Input/Output) interfaces that can connect external devices such as sensors and actuators.

Operating system support:

Compatible with multiple real-time operating systems (RTOS), including VxWorks, Linux, RTEMS, etc., flexibly supporting various industrial application requirements.

Basic applications that support DOS and Windows operating systems.

Scalability:

Provide multiple expansion slots, support additional I/O modules and dedicated cards, and can expand functionality according to specific needs.

It has a PMC (PCI Mezzanine Card) slot that allows for the addition of other hardware modules.

Reliability and Durability:

Designed for industrial grade environments, it has high anti-interference ability and thermal stability.

Having strong error detection and fault tolerance capabilities to ensure stable system operation.

Support temperature range: -40 ° C to+85 ° C, suitable for extreme environmental conditions.

Communication and network capabilities:

Supports Ethernet network interface (usually 10/100 Mbps) for data exchange with remote devices, other control systems, or cloud services.

Provide RS-232/RS-422 serial communication interface, suitable for data transmission with sensors, controllers and other devices.

Application areas:

Industrial automation: used for PLC control systems, robot control, data acquisition systems, etc.

Embedded computing: In embedded control systems, it is used to handle complex tasks such as process control, remote monitoring, etc.

Communication system: Supports high-speed data transmission and is suitable for communication base stations, monitoring systems, etc.

Military and Aerospace: Operating in harsh environments, providing a stable computing platform for flight control, navigation systems, etc.

Technical specifications:

Parameter Description

Processor Motorola 68040 33 MHz

Maximum memory of 128 MB DRAM

Maximum storage capacity of 4 MB Flash

VMEbus Standard VME 64 bit

Multiple RS-232, RS-422 serial ports for I/O interface, Ethernet

Network interface 10/100 Mbps Ethernet

Expand multiple VME slots and support PMC

The operating system supports VxWorks, Linux, RTEMS

Working temperature range -40 ° C to+85 ° C

Power demand+5V DC

Reliable anti vibration and dust-proof design, suitable for industrial environments

Product image
