HONEYWELL SC-UCMX01 51307195-175 Hybrid I/O Module

HONEYWELL SC-UCMX01 51307195-175 Hybrid I/O Module

Product Details Introduction

HONEYWELL SC-UCMX01 51307195-175 hybrid I/O module is a modular hardware used in Honeywell control systems, mainly for data acquisition, signal processing, and control in industrial automation systems. It is part of the Honeywell SC series control system, widely used in process control, equipment monitoring, and automation systems.

SC-UCMX01 51307195-175 Hybrid I/O Module Main Features:

Mixed I/O function:

The SC-UCMX01 module supports mixed input/output functionality and can simultaneously process digital input (DI), digital output (DO), analog input (AI), and analog output (AO) signals. This can integrate multiple different I/O functions in one module, saving system space and wiring complexity.

Supports efficient data collection and control, and can be used in conjunction with different sensors, actuators, and control devices.

High precision analog signal:

Provide high-precision analog input and output, supporting standard voltage and current signals (such as 4-20 mA, 0-10 V, etc.). This precision is crucial for precise control of processes and equipment.

For analog output, it can accurately control the output signals of equipment, such as valve control, motor speed regulation, etc.

Digital input/output:

Digital input is used to collect switch signals and is commonly used for device status monitoring (such as switch sensors, buttons, etc.).

Digital output can be used to control devices such as relays, alarm lights, solenoid valves, etc., providing control signals for actuators.

Modular design:

The modular design allows SC-UCMX01 to be flexibly integrated with other Honeywell series modules, facilitating the expansion of system capacity and functionality.

Support hot swapping, which means replacing or adding modules while the system is running to reduce downtime.

Remote I/O support:

SC-UCMX01 is compatible with Honeywell's remote I/O architecture and supports connection to controllers through communication networks, allowing I/O points to be distributed between field devices and control systems, saving wiring and improving system reliability.

Communication interface:

It is usually compatible with Honeywell Expert PKS and TDC 3000 control systems, supports various industrial communication protocols (such as Modbus RTU/TCP, HART, Profibus, etc.), and can be seamlessly integrated with third-party devices.

Built in diagnostic function, which can monitor and report the status of modules to ensure the stability of system operation.

Reliability and safety:

This module complies with industrial standards, can operate in harsh environments, and has strong anti-interference capabilities.

Equipped with redundant design to improve system availability and fault recovery capabilities, especially suitable for critical process control applications.

Environmental adaptability:

Adapt to a wide range of working temperatures, generally supporting working environments from -20 ° C to+60 ° C, and able to work in industrial sites with large temperature differences.

Capable of resisting vibration, impact, and electromagnetic interference, suitable for harsh industrial environments.

Technical specifications:

Parameter Description

Module type mixed I/O module

Input signal type: Analog input (4-20 mA, 0-10 V), digital input

Output signal type: Analog output (4-20 mA, 0-10 V), digital output

Analog input accuracy of 12 bit or 16 bit (depending on the model)

Digital input/output voltage range 24V DC, compatible with multiple input/output configurations

Supported communication protocols include Modbus RTU/TCP, HART, Profibus, etc

Working temperature range -20 ° C to+60 ° C

The module size is compatible with standard DIN dimensions, making it easy to install and maintain

Power requirement 24V DC

The module installation method supports DIN rail installation, making it easy to deploy on site

Redundancy support supports module redundancy to improve system reliability

The diagnosis and fault detection function is equipped with a built-in diagnostic system, which supports status monitoring and alarm

Product image
