Product Details Introduction

The EATON-MOELLER XV-363-10-C02-A00-1B touch screen is an industrial control panel touch screen jointly produced by Eaton and Moeller. It is widely used in automation control, process monitoring, and data visualization systems, providing operators with an intuitive and easy-to-use interface.

Main features:

High resolution touch screen:

XV-363-10-C02-A00-1B is equipped with a high-resolution touch screen display, which can clearly display various data and graphical interfaces, enhancing the user experience.

Supports TFT LCD screen with delicate display effect, suitable for long-term display of monitoring data.

Multi functional display and control:

It can display real-time process data, system status, and alarm information.

Support touch operation, users can directly operate, adjust parameters, and control the system through the touch screen, simplifying user interaction.

Powerful communication interface:

Supporting multiple industrial communication protocols such as Modbus RTU/TCP, CANopen, Profibus, etc., it can seamlessly connect with various control devices and automation systems (such as PLC, DCS, etc.), ensuring the stability and real-time performance of data transmission.

Flexible interface customization:

Users can design and customize the interface according to their needs, supporting customization of various elements such as icons, buttons, and curve graphs to adapt to different application scenarios.

Collaborate with Eaton's Xsoft CodeSys or other programming tools for graphical interface development to meet complex monitoring requirements.

High reliability and durability:

This touch screen has industrial grade durability and can work stably in harsh environments, including high temperatures, humidity, and electromagnetic interference.

Adopting a sturdy shell, dustproof, waterproof, and vibration resistant, suitable for industrial environments such as factory workshops.

Easy to operate:

The touch screen operation is intuitive and simple, coupled with a customized graphical user interface (GUI), allowing operators to quickly understand the system status and make necessary controls and adjustments.

The touch response is sensitive, reducing the complexity of traditional button operations.

Application areas:

Industrial automation control: used for monitoring and controlling production lines, mechanical equipment, automation devices, etc.

Process monitoring: Provide real-time data display and alarm control in the production process monitoring of chemical, food and beverage, power and other fields.

Building automation: used for controlling building management systems (BMS), including air conditioning, lighting, safety monitoring, and other systems.

Mechanical equipment control: It can be used as an operation panel for various mechanical equipment, providing real-time status information and control interfaces.

Technical specifications:

Parameter Description

Display type: Touch sensitive TFT LCD display screen

Resolution 320 x 240 (may vary depending on specific model)

Touch method: resistive touch or capacitive touch (depending on the model)

Communication interfaces such as Modbus RTU/TCP, CANopen, Profibus, etc

Input voltage 24V DC (typical)

Operating temperature range -10 ° C to+60 ° C

Installation method: panel installation or embedded installation

The size depends on the specific model size (usually 3.5 inches to 12 inches)

Protection level IP65 (front panel waterproof and dustproof)

Durable plastic or metal shell material with anti electromagnetic interference capability

Product image
