Motorola MVME2400-0361 Single Board Computer

Motorola MVME2400-0361 Single Board Computer

Product Details Introduction

The Motorola MVME2400-0361 single board computer is a high-performance VME (Versa Modular Europe) bus compatible single board computer produced by Motorola (now NXP Semiconductors). It is commonly used in fields such as industrial automation, embedded computing, military, and aerospace, providing reliable computing and control capabilities, suitable for environments that require high performance and long-term stability.

Main features:

High performance processor:

MVME2400-0361 is equipped with a PowerPC 603e processor with a clock speed of up to 180 MHz.

The PowerPC architecture is widely used in embedded systems and has excellent computing power and high efficiency.

VME bus compatibility:

Supports VME 64 bus (version 3. x), providing high bandwidth and high-speed data transmission, suitable for systems that require large amounts of data processing.

Can be used as a master control unit or slave device, supporting multiple parallel working modules.

Memory and Scalability:

Provide up to 128 MB of SDRAM (which may vary depending on specific configurations) to meet most embedded computing needs.

Featuring 2 MB of Flash storage, it can be used to store system firmware and applications.

Support for expanding memory and supporting other storage devices (such as CF cards) through PCMCIA slots.

Multiple I/O interfaces:

Equipped with serial port, parallel port, network interface (such as 10/100 Ethernet), supporting USB interface, etc., it can connect with various external devices and control systems.

Provide digital I/O and analog I/O interfaces, which can be used for tasks such as sensor acquisition and actuator control.

Operating system support:

Supports multiple operating systems, including VxWorks, Linux, and RTOS (real-time operating system), enabling it to adapt to applications with various real-time and stability requirements.

Redundancy and reliability:

This single board computer design has high reliability, can operate stably for a long time, and is suitable for applications in harsh environments such as high temperature, low temperature, and vibration.

Equipped with watchdog timer, hardware fault detection and other functions to ensure timely recovery or alarm in case of system failure.

Graphics and display functions:

Provide a graphics accelerator suitable for applications that require a graphical user interface, such as HMI monitoring, industrial control displays, etc.

Application areas:

Industrial automation:

Used for industrial applications such as control systems, data acquisition, monitoring, and analysis. MVME2400 is commonly used in PLC control systems, robot control, and other applications.

Embedded system:

Widely used in embedded systems such as medical equipment, communication equipment, and aerospace systems, it supports real-time data processing and control.

Military and Aerospace:

Due to its high reliability and stability, the MVME2400 series is widely used in military and aerospace applications, especially in control systems that require high durability.

Transportation and Logistics:

Used for real-time data processing and monitoring in intelligent transportation systems, transportation monitoring systems, as well as high-speed railway, aerospace and other systems.

Technical specifications:

Parameter Description

Processor PowerPC 603e, 180 MHz

Memory 128 MB SDRAM

Store 2 MB of Flash

VME Bus VME 64 (Version 3. x)

Network interface 10/100 Ethernet (optional high-speed Ethernet interface)

Serial ports 4 x RS-232 or 2 x RS-232 and 1 x RS-422/485

I/O interfaces include digital I/O, analog I/O, serial port, USB, parallel port, etc

Expansion slot 1 x PMC slot, 1 x PCMCIA slot

Power requirement+5V DC (standard power input)

Size 6U (233 x 160 x 40 mm)

The operating system supports VxWorks, Linux, RTOS (real-time operating system)

The protection level meets the requirements of industrial environment, with anti vibration, dust-proof, and waterproof properties

Product image
