Bently 149992-01 Relay Module

Bently 149992-01 Relay Module

Product Details Introduction

Bently 149992-01 Relay Module is a relay module produced by Bently Nevada Corporation for use in industrial equipment and control systems. Bently Nevada is a company under GE Digital that focuses on equipment health monitoring and predictive maintenance systems, providing high-quality vibration monitoring, machine protection, and asset management products.

Main features:

High reliability and stability:

The Bently 149992-01 relay module has high reliability and is designed for applications that are critical to system safety and protection in industrial environments. It can quickly cut off the circuit or issue an alarm signal in case of equipment failure, thereby preventing greater system damage.

Multi functional protection and control:

This relay module can be used for equipment protection and alarm systems. It can be connected to sensors or monitoring systems to monitor the real-time operation status of devices and trigger protection mechanisms in case of abnormal device operation.

The relay module supports delay setting and multiple alarm functions, which can be adjusted according to different application requirements to ensure that appropriate measures are taken in a timely manner when equipment problems occur.

Wide application scenarios:

This relay module is mainly used in vibration monitoring systems and machine protection systems. It can be integrated into the Bently Nevada 3500 series monitoring system, providing reliable fault diagnosis and real-time alarms.

At the same time, it is also applicable to equipment protection and alarm requirements in other industrial automation systems, such as power, oil and gas, chemical and other industries.

Easy to integrate:

The Bently 149992-01 relay module is designed to be compatible with existing Bently Nevada 3500 series control systems and other automation control systems. Through standard wiring and communication protocols, it can be easily integrated into existing monitoring and control architectures, reducing the complexity of installation and configuration.

Multiple input/output interfaces:

The relay module supports multiple types of input signals, such as digital and analog inputs, as well as output control signals, which can meet complex control requirements.

Provide alarm output and relay switching output, which can directly control external devices such as alarms, shutdown control, etc.

Compact and sturdy design:

The relay module has a sturdy housing design that is suitable for use in harsh environments and can withstand challenges such as vibration, temperature changes, and electromagnetic interference.

The compact appearance allows it to be easily installed in standard industrial racks, saving space and facilitating maintenance.

Application areas:

Vibration monitoring and equipment protection:

Used for Bently Nevada 3500 series vibration monitoring system, it can monitor the operating status of machines (such as motors, pumps, fans, etc.) and issue alarms or power-off protection in case of equipment abnormalities.

It can detect whether the machine has abnormal conditions such as excessive vibration, high temperature, and heavy load, and cut off the power supply in a timely manner to prevent equipment damage.

Industrial control system:

Suitable for various protection and control tasks in industrial automation systems, such as alarm and protection functions for key parameters such as pressure monitoring and flow monitoring.

In heavy industries such as oil and gas, chemical, and power, timely fault alarm and protection are provided for key equipment to ensure the safe operation of the equipment.

Machine Health Management:

Integrated into the health monitoring system, it is used to monitor the real-time operation status of equipment and trigger warning systems in a timely manner, helping maintenance personnel identify potential equipment failures in advance.

Energy and power generation industry:

In key infrastructure such as power plants and substations, provide safety protection for power equipment, timely alarm and disconnect faulty equipment, and prevent further damage.

Technical specifications:

Parameter Description

Input signal type: digital input, analog input (depending on the application)

Output signal type: Relay output (normally open/normally closed), alarm output

Rated working voltage 24V DC (may vary depending on the specific model)

Rated current of relay 5A (normally open/normally closed relay output)

Working temperature range -40 ° C to+70 ° C (depending on the application environment)

Protection level IP20 or suitable for industrial environments according to specific requirements

Size standard industrial size, compatible with 3500 series rack

Electrical interface with connecting terminals, supporting standard industrial wiring methods

Response time in milliseconds to ensure timely protection response

Working humidity range 0% to 95% RH, non condensing state

Product image
