Bently 3500/70M 176449-09 Relay Module

Bently 3500/70M 176449-09 Relay Module

Product Details Introduction

The Bently Nevada 3500/70M 176449-09 relay module is part of the Bently Nevada 3500 series mechanical protection and status monitoring system. This module is designed specifically for industrial environments to handle alarm signals and protection functions for critical mechanical equipment. The following is detailed information about the module:

major function

Alarm processing

Provide alarm driver function and support high reliability alarm signal output.

Capable of responding to multiple conditions within the system that trigger alarms, including overspeed, high bearing temperature, or abnormal vibration.

Relay control

Output signals through mechanical or solid-state relays.

Supports NO (normally open) and NC (normally closed) contact modes.

Modular design

Can be integrated with other modules in the 3500 series framework for customized monitoring and protection needs.

Featuring a plug-in design for easy installation and maintenance.

Diagnosis and redundancy support

Provide self diagnostic function for system operation status.

Support multiple redundant configurations to enhance system reliability and availability.

technical specifications

Model: 3500/70M 176449-09

Output type:

Relay output, supporting multiple alarm types (OK, Warning, Danger, Voting Logic Alarm, etc.).

Contact rating:

Maximum voltage: 250 VAC/30 VDC

Maximum current: 5 A

Working temperature: -30 ° C to+65 ° C

Installation method: Supports insertion into 3500 series racks.

Communication interface: can share data with other 3500 series modules for integration into SCADA or DCS systems within the system.

application area

Rotating machinery protection:

Suitable for alarm triggering and protection functions of equipment such as steam turbines, compressors, generators, pumps, and fans.

Oil and gas industry:

Implement monitoring and safety management of key mechanical equipment.

Industrial manufacturing and power industry:

Used to prevent equipment failures, ensure production continuity and equipment reliability.

Product image
