Bently 3500/72M 176449-08 Monitoring Module

Bently 3500/72M 176449-08 Monitoring Module

Product Details Introduction

The Bently Nevada 3500/72M 176449-08 pressure monitoring module is an important component of the GE Bently Nevada 3500 series protection and monitoring system. This module is designed specifically for pressure monitoring and is suitable for pressure management of various industrial equipment, ensuring safe operation and improving reliability.

major function

Real time pressure monitoring

Capable of accurately measuring the operating pressure of equipment and displaying and analyzing it in real-time through the system.

Provide alarm and danger signals for timely protective measures.

Flexible configuration

Supports multiple input types of pressure sensors (such as 4-20 mA or 0-10 V).

Configurable alarm levels and response thresholds to meet different industrial application requirements.

Modular design

Compatible with Bently Nevada 3500 series frameworks and supports integration with other modules.

Plug in module design, easy to install, disassemble, and maintain.

Alarm function

Provide two independent alarm levels: Warning and Danger.

Support logical voting and event recording functions.

Communication and data integration

Can share data with the system host and support integration with SCADA or DCS systems.

Provide comprehensive data storage and historical analysis capabilities.

technical specifications

Model: 3500/72M 176449-08

Input signal: Supports standard pressure sensor signals (such as 4-20 mA).

Alarm output:

Two configurable alarm outputs (warning and danger).

Measurement range:

It can support a wide range of pressure monitoring based on sensor configuration.

Power supply:

Powered by the 3500 series framework, no separate power supply is required.

Environmental conditions:

Working temperature: -30 ° C to+65 ° C

Relative humidity: 5% -95% (non condensing).

application area

Oil and gas industry

Monitor oil well pressure, oil pipeline pressure, internal pressure of gas turbine, etc.

Power industry

Gas turbine and boiler pressure monitoring.

Chemical and pharmaceutical industries

Pressure measurement and alarm of process equipment.

Industrial manufacturing

Safety management of pressure equipment and gas systems.

Module installation and configuration

Installation method:

Insert the module into the designated slot in the 3500 series rack and use the system configuration tool for initialization and parameter settings.

Configuration tool:

Set up through Bently Nevada 3500 Configuration Software, including sensor type, alarm logic, and response threshold.

Product image
