Product Details Introduction

The ProSoft MVI56-MBP communication module is a Modbus Plus communication module used for Rockwell Automation ControlLogix series PLCs. This module provides the ControlLogix system with the ability to efficiently communicate with Modbus Plus networks, making it suitable for applications in industrial automation, energy, and process control.

main features

Modbus Plus communication support

Provide a single Modbus Plus network interface that supports communication between multiple devices.

Compatible with Modbus Plus protocol specifications, used for data exchange with various Modbus devices.

Integration with ControlLogix system

Seamless integration into the ControlLogix architecture, communicating with the processor through the backplane.

Easily implement data reading and writing using the ControlLogix program.

High performance communication

Supports up to 500 data messages per second, suitable for high demand applications.

Provide fast response time to ensure real-time performance.

Flexible configuration

Use the ProSoft Configuration Builder (PCB) tool for configuration.

Support customizing Modbus Plus network addresses and communication parameters.

Diagnostic function

Provide module status and communication error indicator lights for easy troubleshooting.

Support running status monitoring through software.

technical specifications

Network protocol: Modbus Plus

Interface type: DB9 connector (supports RS-232 serial port configuration)

Backplane communication speed: 5 Mbps

Number of supported devices: up to 32 Modbus Plus nodes

Power requirement: 800 mA @ 5 VDC (powered from ControlLogix rack)

Working temperature: 0 ° C to+60 ° C

Size: Standard ControlLogix I/O module size

Configuration tool: ProSoft Configuration Builder (supported by Windows)

Product image
