IPS21-24V-35AD 3BHE032593R0001 isolated power module

IPS21-24V-35AD 3BHE032593R0001 isolated power module

Product Details Introduction

The Traco TIS600-148-SIG industrial power module is a high-performance and reliable switching power module designed specifically for industrial automation, communication equipment, testing and measurement systems, and other fields. It belongs to Traco Power's TIS series and is widely used in demanding industrial environments due to its high efficiency, wide input voltage range, and superior protection functions.

main features

high efficiency

The TIS600-148-SIG power module adopts advanced switching power supply technology, with a conversion efficiency of over 90%, helping to reduce energy loss and heat generation, and improve equipment stability.

Wide input voltage range

The input voltage range is 85V to 264V AC, enabling it to operate reliably under various power supply conditions.

Adapt to power supply standards in different regions, particularly suitable for applications deployed globally.

Output power:

Provide a maximum output power of 600W, suitable for industrial equipment with high load requirements.

Stable output to meet various precision control and power requirements.

high reliability

Equipped with multiple protection mechanisms, including overload protection, overvoltage protection, over temperature protection, etc., to ensure the safe operation of the system.

Tested to strict industrial standards and adapted to harsh environmental conditions.

Cooling method

Equipped with natural convection cooling, no additional fans are required to reduce noise and maintenance needs.

Improve the reliability and durability of the overall system, suitable for long-term operation.

output characteristic

Single output, providing 48V DC output, suitable for various industrial equipment and applications.

Compact design

Compact design, easy installation, meets the standard 1U height, suitable for rack installation in limited spaces.

Suitable for use in equipment such as cabinets and industrial control panels.

International certification

Obtain UL, CE, RoHS certifications to ensure that products comply with international safety and environmental standards.

technical specifications

Model: TIS600-148-SIG

Input voltage range:

AC input: 85V to 264V AC

DC input: 120V to 370V DC

Output power: 600W

Output voltage: 48V DC

Output current: 12.5A

Efficiency: up to 90% (typical)

Working temperature: -20 ° C to+70 ° C

Storage temperature: -40 ° C to+85 ° C

Environmental humidity: 5% to 95% (no condensation)

Size: 125 x 63.5 x 232 mm (L x W x H)

Cooling method: natural convection cooling

Protection function:

Overvoltage protection (OVP)

Overload Protection (OLP)

Over temperature protection (OTP)

Certification: UL, CE, RoHS, etc

Product image
