Kollmorgen S72402-NANANA servo amplifier

Kollmorgen S72402-NANANA servo amplifier

Product Details Introduction

Kollmorgen S72402-ANANA is a high-performance servo amplifier belonging to the Kollmorgen servo control product series. This amplifier is typically used for precision motion control applications such as automation equipment, robots, CNC machine tools, packaging, and material handling systems. It can be used in conjunction with Kollmorgen's servo motors to achieve efficient motor drive and precise motion control.

The main features of Kollmorgen S72402-NNANA servo amplifier are:

High power output:

S72402-ANANA supports high-power current output and is suitable for driving large or high load servo motors.

compatibility:

Widely compatible with Kollmorgen's own servo motors, DC motors, and AC motors, it can provide support for various types of applications.

High precision control:

Equipped with precise current loop control and position loop control, it can provide high dynamic response and stable control, adapting to the needs of fast movement and precise positioning.

Integrated feedback loop:

Supports incremental encoder or absolute encoder feedback, providing high-precision position feedback to ensure precise control of motor position, speed, and acceleration.

Multiple communication interfaces:

Supports multiple standard communication protocols, such as EtherCAT, CANopen, etc., facilitating integration with the main controller or other automation devices, enhancing the flexibility and scalability of the system.

Overload protection and fault diagnosis:

Built in overload protection, over temperature protection, short circuit protection, and fault diagnosis functions to improve the reliability and safety of the system.

Energy saving mode:

Efficient energy utilization design that can automatically adjust power output according to load demand, reducing energy loss.

Compact design:

Compact design, suitable for installation in control cabinets or machinery equipment with limited space.

Easy to set up and debug:

Through the debugging tools provided by Kollmorgen, users can easily perform system debugging, parameter settings, and optimization.

technical specifications

Voltage: Supports different voltage inputs, usually AC power supply (e.g. three-phase 400V AC).

Current output: Depending on the model, the output current range can vary from several amperes to several hundred amperes, meeting the needs of different motors.

Feedback type: Supports incremental encoders and absolute encoders to ensure high-precision closed-loop control.

Communication interfaces: Common ones include EtherCAT, CANopen, Modbus, RS232/RS485, etc., supporting communication with upper computers or other automation devices.

Temperature range: The working environment temperature is usually between -10 ° C and 50 ° C, suitable for most industrial applications.

application area

Automated production line: suitable for industrial automation scenarios such as packaging, conveying, and handling, capable of accurately controlling the movement of robotic arms or conveyor belts.

CNC machine tool: used for high-precision driving of CNC machine tools, providing stable control performance and ensuring machining accuracy.

Robot technology: In robot systems, it provides precise motion control, adapts to complex trajectories, and operates at high speeds.

Printing and Material Processing: Provides efficient and precise motor control in high-speed printers and material processing equipment.

Stereoscopic warehouse and logistics system: used for warehouse management and automated logistics transmission system.

Product image
