Product Details Introduction

The Watlow AnaFaze CLS208 C10000CP temperature controller is a high-performance multi loop temperature controller designed for precise control of multiple temperature or process variables in industrial processes. It is suitable for application scenarios that require flexibility, high reliability, and compact design, such as semiconductor processing, heat treatment, packaging equipment, and industrial furnaces.

main features

Multi loop control

Supports up to 8 independent control circuits.

Each circuit can independently configure parameters and control modes, providing great application flexibility.

Advanced Control Algorithm

Provide PID control algorithm and support adaptive adjustment function.

Equipped with preset control modes (heating, cooling, or bidirectional control) to adapt to different process requirements.

Compact design

Compact DIN rail installation structure saves control cabinet space.

Integrated high-density I/O interface, supporting multiple input/output configurations.

Multiple input support

Supports multiple types of temperature sensors such as thermocouples (TC), RTDs, linear inputs, etc.

Wide input range and strong compatibility.

Communication capability

Provide serial communication interfaces such as RS-232 or RS-485.

Supports Modbus RTU protocol for easy integration with PLC or upper computer.

high reliability

Industrial grade design, resistant to electromagnetic interference, suitable for harsh environments.

Built in alarm function, which can provide timely warnings for abnormal temperature.

Easy to configure and use

Provide a user-friendly programming interface that allows for easy parameter settings through computer software or panel buttons.

Support local and remote monitoring operations.

technical parameter

Input type

Thermocouples: common types such as J, K, T, E, N, etc.

RTD: 2-wire or 3-wire PT100, PT1000.

Voltage or current signal: 0-10V, 4-20mA.

type of output

Relay output: used for heating or cooling equipment.

SSR driver output: controls solid-state relays.

Analog output: Provides 0-10V or 4-20mA signals.

Power Supply

Input voltage: 85-265V AC or 24V DC (specific models may vary).

Environmental requirements

Working temperature: 0 ° C to 50 ° C.

Storage temperature: -20 ° C to 70 ° C.

Humidity: 10% to 90% (without condensation).

Size and Installation

Compact design, supporting DIN rail installation or panel installation.

The external dimensions vary depending on the specific model.

Product imag
