BENTLY 3500/44M 176449-03U Vibration Monitor

BENTLY 3500/44M 176449-03U Vibration Monitor

Product Details Introduction

The Bently Nevada 3500/44M 176449-03U vibration monitor is part of the Bently Nevada 3500 series monitoring system, used to monitor and protect mechanical equipment vibration, bearing vibration, and unit health. Its design is suitable for critical rotating machinery such as steam turbines, compressors, and generators, providing reliable data support for the safe operation and maintenance of industrial equipment.

Product Features

Multi functional vibration monitoring

Support multiple vibration parameter monitoring, including absolute vibration, relative vibration, and bearing vibration.

Provide high-precision data collection and real-time monitoring.

Modular design

Compatible with Bently Nevada 3500 series framework systems.

Can be used in conjunction with other modules to meet different monitoring needs.

Flexible input configuration

Supports multiple types of sensors, including accelerometers, velocity sensors, and displacement sensors.

Each channel can independently configure input parameters, flexibly adapting to multiple applications.

Alarm function

Support alarm limit setting, including warning and danger levels.

Provide relay output for triggering protective devices or issuing alarm signals.

data communication

Support seamless integration with 3500 series systems, enabling remote monitoring and data analysis through system communication modules.

high reliability

Industrial grade design, adaptable to harsh environments, and resistant to electromagnetic interference.

Provide redundant configuration options to ensure high availability of the system in critical applications.

technical parameter

Number of channels

Supports vibration monitoring for up to 4 channels.

Input type

Compatible with the following sensors:

Accelerometer

speed sensor

Displacement sensors (such as eddy current probes)

type of output

Relay output: used for alarm triggering or protection system linkage.

Analog output: Provides 4-20mA signal and supports integration with other systems.

Alarm settings

Support user-defined alarm thresholds:

Warning

Danger

Provide automatic and manual reset options.

Power requirements

Working voltage: 24V DC or powered by 3500 series rack.

work environment

Temperature range: -30 ° C to+65 ° C.

Humidity range: 5% to 95% (without condensation).

Installation method

Installed in the 3500 series rack and secured through standard slots.

Product imag
