Product Details Introduction

The GE IC3603A282A inverter module is an industrial power electronics module provided by General Electric (GE), mainly used for the mutual conversion of AC power and DC power, widely used in industrial automation, energy management, and control systems. The following are detailed technical specifications and application information:

Product Overview

Product model: IC3603A282A

Module type: inverter module

Main function: Convert direct current to alternating current to drive industrial equipment or supply power to other modules.

Technical features

Power conversion:

Input voltage range: Supports standard industrial DC voltage input (specific confirmation document required).

Output voltage range: Typically output as standard AC voltage, suitable for driving industrial loads.

Output waveform: Provides high-quality sine wave output, suitable for precision equipment operation.

Efficiency:

High inverter efficiency can effectively reduce energy loss.

Supports multiple working modes (such as continuous or intermittent operation).

Protection function:

Equipped with overload protection, short circuit protection, and over temperature protection functions to ensure system safety.

Support automatic recovery function to restore normal operation after troubleshooting.

Structure and Interface:

Compact design, suitable for installation in control cabinets with limited space.

Provide standard industrial interfaces that are easy to integrate with other devices.

application area

Industrial automation:

Provide power support for frequency converters and servo drives.

Motors and sensors drive in the factory.

Energy Management:

Inverter unit as a backup power source.

In photovoltaic systems, direct current is converted to alternating current for grid connection.

Power equipment:

Provide stable AC power supply to drive sensitive electrical equipment.

Product imag
