Bently 3500/32M 149986-02 Relay Module

Bently 3500/32M 149986-02 Relay Module

Product Details Introduction

The Bently Nevada 3500/32M 149986-02 relay module is a critical component in the 3500 system, typically used for mechanical protection and condition monitoring systems. It is mainly used to output signals for alarm or shutdown events, facilitating users to respond and control the device status accordingly.

Main features of the product

Relay channel:

Provide 4 relay output channels, supporting independent configuration.

Can be configured to trigger an alarm or shutdown event.

Configurability:

Support user-defined configuration and can adapt to various alarm or shutdown logic requirements.

Implement programming settings through 3500 configuration software.

Reliability:

Designed to meet high reliability industrial standards and suitable for long-term operation in harsh environments.

Support redundant architecture to ensure high availability of the system.

Status indication:

Built in LED indicator lights are used to display the status (active or inactive) of each channel.

compatibility:

Compatible with 3500 frames and other modules, making it easy to integrate into Bently Nevada mechanical protection systems.

Installation:

Plug in design, easy to install and replace.

Occupy a slot.

technical specifications

Power requirement: Powered by a 3500 frame.

Contact rating:

Maximum current: 5A

Maximum voltage: 250VAC or 30VDC

Contact type:

Normally open (NO)

Normally closed (NC)

Working temperature:- 30 ° C to+65 ° C

Storage temperature:- 40 ° C to+85 ° C

Humidity: 5% to 95% (without condensation)

Product imag
