Bently 3500/33 149986-01 Relay Module

Bently 3500/33 149986-01 Relay Module

Product Details Introduction

The Bently Nevada 3500/33 149986-01 relay module is an important component of the 3500 series mechanical protection and monitoring system, used to provide flexible alarm and shutdown control functions for industrial equipment. This module is designed specifically for critical rotating equipment and mechanical systems, capable of issuing alarms or triggering shutdowns in case of abnormal equipment operation to protect equipment and personnel safety.

Main features of the product

Multi channel design

Provide 4 relay output channels, each of which can be independently configured.

Support different types of alarm conditions, such as high vibration, overspeed, abnormal bearing temperature, etc.

Flexible configuration

Supports multiple alarm logics, including Alert and Danger.

Easily implement logic programming through 3500 configuration software to meet complex monitoring requirements.

Modular design

Occupy one rack slot for easy installation, replacement, and system expansion.

Fully compatible with other 3500 modules.

high reliability

Industrial grade design, suitable for harsh environments such as high temperature and high humidity.

Support redundant configuration and provide higher system reliability.

Status indication

Equipped with LED indicator lights to display the working status of each relay channel.

Easy to quickly diagnose relay triggering and equipment status.

technical specifications

Number of relay channels: 4

Contact type:

Single Knife Double Throw (SPDT)

Supports normally open (NO) and normally closed (NC) contacts.

Contact rating:

Maximum current: 5A

Maximum voltage: 250VAC or 30VDC

Power requirement: Powered by a 3500 frame

Working temperature:- 30 ° C to+65 ° C

Storage temperature:- 40 ° C to+85 ° C

Humidity range: 5% to 95% (without condensation)

Installation method: Plug in design, occupying one 3500 frame slot.

Product imag
