ABB RED670 display panel

ABB RED670 display panel

Product Details Introduction

The ABB RED670 display panel is an important component of ABB's protection and control equipment, and is part of the RED670 differential protection device series. It is used to display the operating status, parameter information, and fault records of the device, providing an intuitive user interface.

Overview of RED670 Display Panel Functions

Real time monitoring:

Display real-time device operation status and protection function status.

Provide operational parameters of the power grid, such as current, voltage, power, frequency, etc.

Event record:

Display historical events and fault records.

Support timestamp to help users quickly locate and analyze faults.

Alarm prompt:

Notify equipment abnormalities through visual or audible alarms.

Indicate protection start, trip or other status information.

User interaction:

Allow users to set parameters and select modes through the panel.

Equipped with function keys and navigation keys for easy operation.

Intuitive display:

Equipped with a high-resolution display screen, displaying clear text, charts, and warning signs.

The interface layout can be customized according to user needs.

Physical characteristics of display panel

Characteristic Description

Screen type: LCD or high brightness LED display screen

Button layout, physical buttons or touch support

Language support for multiple languages, including English and Chinese, etc

Standardized dimensions for easy integration and installation of the front panel

Clear distribution of indicator lights such as status lights and alarms

Product imag
