Bently 3500/70M 140734-09 Dynamic Pressure Monitor

Bently 3500/70M 140734-09 Dynamic Pressure Monitor

Product Details Introduction

The Bently Nevada 3500/70M (140734-09) Dynamic Pressure Monitor Module is a highly specialized monitoring device designed for real-time monitoring of dynamic pressure changes in industrial equipment. This module is used to detect rapidly changing pressure signals, such as vibrations and shock waves from gas turbines, compressors, or other high dynamic pressure equipment, in order to protect the equipment and improve its operational efficiency.

Product Overview

Attribute Details

Model 3500/70M

Order number 140734-09

Equipment type: Dynamic pressure monitor module

Bently Nevada 3500 Series

Main functions: real-time dynamic pressure monitoring, analysis, and alarm

Installation position: Installed in the 3500 frame

Key features

Dynamic pressure monitoring:

Specially designed for detecting rapidly changing pressure signals, suitable for high dynamic environments.

Can capture pressure pulses, shock waves, and vibration signals related to device operation.

High resolution signal processing:

Built in high-performance digital signal processing (DSP) unit, capable of real-time analysis of dynamic signals.

Supports a wide frequency range, suitable for capturing high-frequency pressure changes.

Alarm and protection functions:

Equipped with Alert and Danger level alarm functions.

Support custom setting of alarm thresholds to adapt to different devices and applications.

Multi channel input:

Provide multiple pressure sensor input channels, each channel can be configured separately.

Compatible with multiple dynamic pressure sensors.

Modular design:

Support hot swapping, convenient for on-site replacement or upgrade, without the need for downtime.

It can seamlessly integrate with other 3500 series modules to achieve complete device monitoring and protection.

Data analysis and communication:

Can be connected to the system control center to provide real-time data and historical trend records.

Support data bus communication and share data with other modules.

Product imag
