ABB AI810 3BSE008516R0001 Analysis Input Module

ABB AI810 3BSE008516R0001 Analysis Input Module

Product Details Introduction

The ABB AI810 3BSE008516R0001 analog input module is a high-performance module designed for ABB control systems, specifically designed to receive analog signals and convert them into digital signals. It is widely used in industrial automation applications and is suitable for various process control and monitoring tasks.

Product Overview

Function:

Receive analog signals (such as voltage or current) from sensors or other devices.

Convert analog signals into digital signals for processing by the control system.

compatibility:

Compatible with ABB's 800xA and AC800M series control systems.

Suitable for data collection and monitoring in industrial environments.

High reliability:

Modular design, easy to install and maintain.

Capable of stable operation in harsh industrial environments.

technical specifications

Parameter specification description

Module model AI810

Part number 3BSE008516R0001

8 analog input channels

Signal type: Current signal (4-20 mA)

Input range 0 to 20 mA or 4 to 20 mA

Resolution of 12 bits

Isolation protection between channels and systems

Supply voltage 24 V DC

Working temperature -20 ° C to 55 ° C

Compact size design, suitable for standard control cabinet installation

The communication protocol supports PROFIBUS and other industry standard protocols

Product imag
