Bently 3500/64M 176449-05 Pressure Monitoring Module

Bently 3500/64M 176449-05 Pressure Monitoring Module

Product Details Introduction

The Bently Nevada 3500/64M 176449-05 pressure monitoring module is a universal pressure monitoring module designed specifically for vibration and condition monitoring of mechanical equipment. It is part of the Bently Nevada 3500 series and is primarily used for pressure signal measurement, monitoring, and protection in critical equipment such as turbines, compressors, and pumps.

Product Overview

Model: 3500/64M 176449-05

Brand: Bently Nevada

Function: Real time measurement and monitoring of pressure signals, providing operational status data of mechanical equipment, supporting alarm and protection functions.

Key technical parameters

Parameter description

Input signal supports differential and single ended pressure sensor signal input

Input range ± 20 mA or ± 10 V, flexible selection according to configuration

The number of channels supports 4 pressure input channels

Resolution 16 bit high-precision analog-to-digital conversion

The alarm function has warning and danger alarm levels to ensure timely fault response

The communication interface supports communication with the 3500 series framework and provides data integration capabilities

Configure software using Bently Nevada 3500 series system configuration tool

The power demand is supplied through the 3500 framework

Working temperature -30 ° C to+65 ° C

The external dimensions comply with the standard dimensions of the 3500 series module

Certification standards comply with API 670 and other industry standards

Product imag
