ABB IMHSS03 hydraulic servo module

ABB IMHSS03 is a hydraulic servo module used for precise control of actuators in hydraulic systems, such as hydraulic cylinders or hydraulic motors. It is commonly used in industrial automation, metal processing, plastic machinery, machine tool control, and heavy-duty industrial equipment to achieve high-precision hydraulic servo control.

1. Product Overview

manufacturer: ABB（Asea Brown Boveri）

Product model: IMHSS03

Product type: Hydraulic Servo Module

Application areas:

Hydraulic Drive for CNC Machine Tools

Hydraulic control equipment such as injection molding machines and stamping machines

Hydraulic servo systems for industries such as steel, papermaking, and energy

Other precision hydraulic control applications

2. Technical parameters

Parameter specifications

Control type: Hydraulic servo control

Input voltage 24V DC or higher (depending on system configuration)

The communication interface may support PROFIBUS, Modbus, or CANopen (please refer to the model description for details)

High precision closed-loop hydraulic control with high control accuracy

Compatibility with ABB PLC DCS、 Motion control system

ABB IMHSS03 achieves precise control of hydraulic systems through electronic servo valves or proportional valves, with high dynamic response capability.

3. Main functions

✅  High precision hydraulic control: suitable for complex industrial environments, achieving precise control of pressure, flow rate, and position.

✅  Closed loop feedback system: Combining hydraulic sensors (such as pressure sensors and displacement sensors) to optimize control accuracy.

✅  Modular design: supports quick installation and replacement, suitable for different hydraulic systems.

✅  Intelligent diagnosis and protection: equipped with functions such as fault alarm, overload protection, and pressure anomaly detection.

✅  Strong compatibility: can be integrated into ABB PLC, DCS or industrial control systems.

Product imag
