DANAHER ZMP-SYNQNET-PCI Motion Control Module

DANAHER ZMP-SYNQNET-PCI is a high-performance PCI motion control module used in multi axis motion control systems, mainly applied in precision automation, robotics, CNC machine tools, semiconductor manufacturing, electronic assembly and other fields. It adopts SynqNet as the communication protocol, providing high-speed and real-time distributed motion control, suitable for high-precision synchronous control and applications with complex motion trajectories.

1. Product Overview

manufacturer: DANAHER Motion

Product model: ZMP-SYNQNET-PCI

Product type: PCI motion control module

Bus interface: PCI (standard 32-bit slot)

Communication Protocol: SynqNet (High bandwidth Real time Motion Control Network)

Typical applications:

Multi axis motion control (CNC machine tools, robots)

Electronic manufacturing, semiconductor equipment

3D printing, laser cutting, optical inspection

Automated assembly line

High precision positioning system

2. Main technical parameters

Parameter specifications

Communication interface PCI bus

Control Network SynqNet

Supports 4-32 axes (depending on configuration)

Data transmission rate up to 100Mbps

Synchronization accuracy nanosecond level (suitable for high-precision synchronization control)

I/O expansion compatible with external I/O modules

Feedback support supports multiple encoder feedbacks (incremental/absolute encoder)

Operating system compatibility with Windows/Linux (based on dedicated SDK)

Real time hardware level real-time performance, supporting motion trajectory planning

Typical control methods include position control, speed control, and torque control

Product imag
