ABB RTU560 560CMD11 communication unit

ABB RTU560 560CMD11 communication unit

Product Details Introduction

ABB RTU560 560CMD11 is a communication module in the ABB RTU560 Remote Terminal Unit (RTU) series, mainly used for industrial automation, energy management, power dispatch, and substation automation systems (SAS). It provides multiple communication protocols, supports remote monitoring, data acquisition (SCADA), and efficient data exchange with the main station or other intelligent electronic devices (IEDs).

1. Product Overview

manufacturer: ABB

Product series: RTU560

Model: 560CMD11

Equipment type: Communication Unit

Main functions:

As the communication interface of the RTU560 system, it provides remote and local communication capabilities

Supports multiple protocols (IEC 60870-5-101/104, DNP3, Modbus, PROFIBUS, etc.)

Data collection and processing can be integrated into SCADA or EMS (Energy Management System)

Compatible with other I/O, control, and interface modules of RTU560

2. Main technical parameters

Parameter specifications

Supply voltage 24V DC or 48V DC (depending on configuration)

Typical power consumption: 5W-10W

Communication interface Ethernet (RJ45), RS232, RS485, fiber optic interface

Supporting protocol IEC 60870-5-101/104 DNP3、Modbus、PROFIBUS、OPC

I/O supports expandable DI DO、AI、AO

Installation method: Rack mounted/DIN rail

Environmental temperature -25 ° C to+70 ° C (industrial grade)

Protection level IP20 (suitable for use inside control cabinets)

Compatible with ABB RTU560 and other industrial communication equipment

Product imag
